3CX SM JCB 3CX SM Specifications & Technical Data (2008—2016)

The JCB 3CX SM is a backhoe loader manufactured by JCB from 2008 to 2016. It has a weight of 8.1 tons and a transport length of 5.…

The JCB 3CX SM is a backhoe loader manufactured by JCB from 2008 to 2016. It has a weight of 8.1 tons and a transport length of 5.62 meters. The bucket capacity is 1 cubic meter, with a tear-out force of 31.63 kN. It can dredge up to a depth of 5.97 meters and has a bucket width of 2.35 meters. The maximum discharge height is 2.74 meters, and it can reach horizontally up to 6.52 meters. The transport width is 2.24 meters, and the transport height is 3.61 meters. It is equipped with special features such as a clamshell, forklift utility, and outrigger stabilizers.

Visit JCB live at

3CX SM

Years of manufacture: 2008—2016

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events
News

Technical specs - 3CX SM JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 8.1 t

Standard tyres: 18.4-26

Bucket width: 2.35 m

Bucket capacity: 1 m³

Drive: A

Transport length: 5.62 m

Transport width: 2.24 m

Transport height: 3.61 m

Tear-out force: 31.63 kN

Max. Reach horizontal: 6.52 m

Dredging depth: 5.97 m

Max. discharge height: 2.74 m

Model series: CX

Engine manuf.: JCB

Engine type: 444

Engine power: 74.2 kW

More technical details, like: bucket capacity backhoe, tear-out force backhoe, travel speed, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: Yes
Clamshell: Yes
Forklift utility: Yes
Grabber: No
Diesel particulate filter: No
Aircondition: No

Download datasheets (PDF)

3CX SM JCB Specification for Europe (EN)

JCB 3CX SM FAQ

When was the JCB 3CX SM manufactured?

The JCB 3CX SM was manufactured from 2008 to 2016.

How much does the JCB 3CX SM backhoe loader weigh?

The JCB 3CX SM backhoe loader weighs 8.1 tons.

What are the transport dimensions of the JCB 3CX SM backhoe loader?

The JCB 3CX SM has a transport length of 5.62 meters, a transport width of 2.24 meters, and a transport height of 3.61 meters.

What are the undercarriage specifications of the JCB 3CX SM backhoe loader?

The JCB 3CX SM backhoe loader features an all-wheel drive system and standard tyres sized 18.4-26.

What are the excavation performance specifications of the JCB 3CX SM backhoe loader?

The JCB 3CX SM backhoe loader has a dredging depth of 5.97 meters and a maximum horizontal reach of 6.52 meters.

What are the power ratings of the JCB 3CX SM backhoe loader?

The source data does not provide power rating information for the JCB 3CX SM backhoe loader. However, it has a tear-out force of 31.63 kN.

What is the maximum discharge height of the JCB 3CX SM?

The JCB 3CX SM has a maximum discharge height of 2.74 meters.

What are the specifications of the primary work tool bucket on the JCB 3CX SM?

The primary work tool bucket of the JCB 3CX SM has a capacity of 1 cubic meter and a width of 2.35 meters.

How much is a JCB 3CX SM Backhoe loader (2008u20132016) worth?

The residual value of the JCB 3CX SM depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
