210 SU JCB 210 SU Specifications & Technical Data (1997—2004)

The JCB 210 SU Backhoe Loader, manufactured from 1997 to 2004, is a construction machine with a weight of 4.453 tons. It has a tra…

The JCB 210 SU Backhoe Loader, manufactured from 1997 to 2004, is a construction machine with a weight of 4.453 tons. It has a transport length of 4.88 meters and a bucket capacity of 0.06 cubic meters. The dredging depth is 3.65 meters, while the bucket width is 1.22 meters. The maximum discharge height is 4.41 meters, and it has a maximum reach horizontal of 5.51 meters. With a travel speed of 31.5 km/h, it has a transport width of 1.85 meters and a transport height of 2.55 meters.

Backhoe Loaders JCB 210 SU

Visit JCB live at

Technical specs - 210 SU JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
4.453 t
Standard tyres
12.5x18.1PR
Bucket width
1.22 m
Bucket capacity
0.06 m³
Drive
A
Transport length
4.88 m
Transport width
1.85 m
Transport height
2.55 m
Max. Reach horizontal
5.51 m
Dredging depth
3.65 m
Max. discharge height
4.41 m
Travel speed
31.5 km/h
Engine manuf.
Perkins
Engine type
1000
Engine power
48.5 kW
Displacement
4 l
Revolutions at max torque
2000 rpm
Max. torque
228 Nm
No. of cylinders
4
Cylinder bore x stroke
100x127 mm

More technical details, like: bucket capacity backhoe, tear-out force, tear-out force backhoe, model series, dimension lxwxh, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers
No
Clamshell
No
Forklift utility
No
Grabber
No
Diesel particulate filter
No
Aircondition
No

Download datasheets (PDF)

JCB 210 SU FAQ

When was the JCB 210 SU manufactured?

The JCB 210 SU was manufactured from 1997 to 2004.

How much does the JCB 210 SU backhoe loader weigh?

The JCB 210 SU backhoe loader weighs 4.45 tons.

What are the transport dimensions of the JCB 210 SU backhoe loader?

The JCB 210 SU has a transport length of 4.88 meters, a transport width of 1.85 meters, and a transport height of 2.55 meters.

What is the travel speed of the JCB 210 SU backhoe loader?

The JCB 210 SU backhoe loader has a travel speed of 31.5 km/h.

What are the undercarriage specifications of the JCB 210 SU backhoe loader?

The JCB 210 SU backhoe loader features an all-wheel drive and standard tyres sized 12.5x18.1PR.

What are the dredging depth and maximum horizontal reach of the JCB 210 SU backhoe loader?

The JCB 210 SU backhoe loader has a dredging depth of 3.65 meters and a maximum horizontal reach of 5.51 meters.

What is the material handling capacity of the JCB 210 SU in terms of discharge height?

The JCB 210 SU has a maximum discharge height of 4.41 meters.

What are the specifications of the primary work tool bucket on the JCB 210 SU backhoe loader?

The JCB 210 SU backhoe loader has a bucket with a capacity of 0.06 cubic meters and a width of 1.22 meters.

How much is a JCB 210 SU Backhoe loader (1997u20132004) worth?

The residual value of the JCB 210 SU depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
