1700 B JCB 1700 B Specifications & Technical Data (1989—1995)
Visit JCB live at
.jpg){kind=logo}
Technical specs - 1700 B JCB
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 7.48 t
- Standard tyres
- F: 12.5Lx16 12PR. R: 19.5x24 12PR
- Bucket width
- 2.44 m
- Bucket capacity
- 1.16 m³
- Bucket capacity backhoe
- 0.35 m³
- Drive
- A
- Transport length
- 7.7 m
- Transport width
- 2.44 m
- Transport height
- 4.14 m
- Max. Reach horizontal
- 8.89 m
- Dredging depth
- 6.53 m
- Max. discharge height
- 7.29 m
- Travel speed
- 33.2 km/h
- Engine manuf.
- Perkins
- Engine type
- 1004 T3HR
- Engine power
- 70.5 kW
- Displacement
- 4 l
- Revolutions at max torque
- 2200 rpm
- Max. torque
- 357 Nm
- No. of cylinders
- 4
- Cylinder bore x stroke
- 100x127 mm
More technical details, like: tear-out force, tear-out force backhoe, model series, dimension lxwxh, emission level are available in the full technical specs.
Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket
Special equipment
- Outrigger stabilisers
-
Yes
- Clamshell
-
No
- Forklift utility
-
No
- Grabber
-
No
- Diesel particulate filter
-
No
- Aircondition
-
Yes
