436 II Caterpillar 436 II Specifications & Technical Data (1991—2026)

The Caterpillar 436 II is a backhoe loader that has been manufactured since 1991. It weighs 6.88 tons and has a transport length o…

The Caterpillar 436 II is a backhoe loader that has been manufactured since 1991. It weighs 6.88 tons and has a transport length of 7.09 meters. The bucket capacity is 1 cubic meter, with a tear-out force of 35.1 kilonewtons. It can dredge up to a depth of 4.91 meters and has a bucket width of 2.26 meters. The maximum discharge height is 2.62 meters, and it has a maximum reach of 7.14 meters horizontally. The travel speed is 29.7 kilometers per hour. The transport width is 2.26 meters, and the transport height is 3.81 meters. The backhoe has a bucket capacity of 0 cubic meters and a tear-out force of 48.9 kilonewtons.

Backhoe Loaders Caterpillar 436 II

Technical specs - 436 II Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
6.88 t
Standard tyres
F: 11.00-16 L2 PR/R: 16.9-28 10 PR
Bucket width
2.26 m
Bucket capacity
1 m³
Bucket capacity backhoe
0.16-0.3 m³
Transport length
7.09 m
Transport width
2.26 m
Transport height
3.81 m
Tear-out force
35.1 kN
Tear-out force backhoe
48.9 kN
Max. Reach horizontal
7.14 m
Dredging depth
4.91 m
Max. discharge height
2.62 m
Travel speed
29.7 km/h
Engine manuf.
Perkins
Engine type
4.236
Engine power
57.5 kW

More technical details, like: drive, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers
No
Clamshell
No
Forklift utility
No
Grabber
No
Diesel particulate filter
No
Aircondition
No

Download specalog and datasheets (PDF)

Caterpillar 436 II FAQ

When was the Caterpillar 436 II manufactured?

The Caterpillar 436 II was first produced in 1991.

How much does the Caterpillar 436 II backhoe loader weigh?

The Caterpillar 436 II backhoe loader weighs 6.88 tons.

What are the transport dimensions of the Caterpillar 436 II backhoe loader?

The Caterpillar 436 II has a transport length of 7.09 meters, a transport width of 2.26 meters, and a transport height of 3.81 meters.

What is the travel speed of the Caterpillar 436 II backhoe loader?

The Caterpillar 436 II backhoe loader has a travel speed of 29.7 km/h.

What are the undercarriage tyre specifications of the Caterpillar 436 II backhoe loader?

The Caterpillar 436 II backhoe loader has standard tyres with front tyres sized 11.00-16 L2 PR and rear tyres sized 16.9-28 10 PR.

What are the excavation performance specifications of the Caterpillar 436 II backhoe loader?

The Caterpillar 436 II has a dredging depth of 4.91 meters and a maximum horizontal reach of 7.14 meters.

What are the tear-out forces of the Caterpillar 436 II backhoe loader?

The Caterpillar 436 II has a tear-out force of 35.1 kN and a backhoe tear-out force of 48.9 kN.

What is the material handling capacity of the Caterpillar 436 II in terms of maximum discharge height?

The Caterpillar 436 II has a maximum discharge height of 2.62 meters.

What are the specifications of the primary work tool bucket on the Caterpillar 436 II?

The primary work tool bucket of the Caterpillar 436 II has a capacity of 1 cubic meter and a width of 2.26 meters.
