430F Caterpillar 430F Specifications & Technical Data (2012—2026)

The Caterpillar 430F is a backhoe loader that has been manufactured since 2012. It weighs 11 tons and has a transport length of 7.…

The Caterpillar 430F is a backhoe loader that has been manufactured since 2012. It weighs 11 tons and has a transport length of 7.282 meters. The bucket capacity is 1 cubic meter, with a tear-out force of 49.8 kilonewtons. It can dredge up to a depth of 4.698 meters and has a bucket width of 2.406 meters. The maximum discharge height is 2.746 meters, and it can reach horizontally up to 6.043 meters. The travel speed of this machine is 40 kilometers per hour. It has a transport width of 2.322 meters and a transport height of 3.577 meters. The tear-out force of the backhoe is 71.86 kilonewtons. Special equipment includes a diesel particulate filter and outrigger stabilizers.

430F

Years of manufacture: 2012—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 430F Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 11 t

Standard tyres: 12.5/80-18 (12 ply) 1-3/19.5L-24 (12 ply) ATU

Bucket width: 2.406 m

Bucket capacity: 1 m³

Drive: A

Transport length: 7.282 m

Transport width: 2.322 m

Transport height: 3.577 m

Tear-out force: 49.8 kN

Tear-out force backhoe: 71.86 kN

Max. Reach horizontal: 6.043 m

Dredging depth: 4.698 m

Max. discharge height: 2.746 m

Travel speed: 40 km/h

Engine manuf.: Caterpillar

Engine type: 3054C DIT

Engine power: 70 kW

Displacement: 4.4 l

Revolutions at max torque: 1400 rpm

Max. torque: 487 Nm

Cylinder bore x stroke: 105x127 mm

Emission level: U.S. EPA Tier 2/EU Stage II

More technical details, like: bucket capacity backhoe, model series, dimension lxwxh, no. of cylinders are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: Yes
Clamshell: No
Forklift utility: No
Grabber: No
Diesel particulate filter: Yes
Aircondition: No

Download specalog and datasheets (PDF)

Caterpillar 430F FAQ

When was the Caterpillar 430F backhoe loader first manufactured?

The Caterpillar 430F backhoe loader was first produced in 2012.

How much does the Caterpillar 430F backhoe loader weigh?

The Caterpillar 430F backhoe loader weighs 11 tons.

What are the transport dimensions of the Caterpillar 430F backhoe loader?

The Caterpillar 430F has a transport length of 7.28 meters, a transport width of 2.32 meters, and a transport height of 3.58 meters.

What is the travel speed of the Caterpillar 430F backhoe loader?

The Caterpillar 430F backhoe loader has a travel speed of 40 km/h.

What are the undercarriage specifications of the Caterpillar 430F backhoe loader?

The Caterpillar 430F backhoe loader features an all-wheel drive system and standard tyres sized 12.5/80-18 (12 ply) and 1-3/19.5L-24 (12 ply) ATU.

What is the excavation performance of the Caterpillar 430F backhoe loader?

The Caterpillar 430F backhoe loader has a dredging depth of 4.698 meters and a maximum horizontal reach of 6.043 meters.

What are the tear-out forces of the Caterpillar 430F backhoe loader?

The Caterpillar 430F has a tear-out force of 49.8 kN and a backhoe tear-out force of 71.86 kN.

What is the maximum discharge height of the Caterpillar 430F?

The Caterpillar 430F has a maximum discharge height of 2.75 meters.

What are the specifications of the primary work tool bucket on the Caterpillar 430F?

The primary work tool bucket of the Caterpillar 430F has a capacity of 1 cubic meter and a width of 2.41 meters.
