427F2 Caterpillar 427F2 Specifications & Technical Data (2013—2019)

Model rating: 7,50 / 10

The Caterpillar 427F2 is a backhoe loader manufactured from 2013 to 2019. It has a weight of 8.11 tons and a transport length of 5…

The Caterpillar 427F2 is a backhoe loader manufactured from 2013 to 2019. It has a weight of 8.11 tons and a transport length of 5.7 meters. The bucket capacity is 1.03 cubic meters, with a tear-out force of 54.8 kN. It can dredge up to a depth of 4.28 meters and has a bucket width of 2.41 meters. The maximum discharge height is 2.8 meters, and it can reach a maximum horizontal distance of 5.65 meters. The travel speed is 40 km/h. The transport width is 2.35 meters, and the transport height is 3.78 meters. The backhoe tear-out force is 63.4 kN.

427F2

Years of manufacture: 2013—2019

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 427F2 Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 8.11 t

Standard tyres: VR 12.5/80-18 HR 16.9-28

Bucket width: 2.41 m

Bucket capacity: 1.03 m³

Drive: A

Transport length: 5.7 m

Transport width: 2.35 m

Transport height: 3.78 m

Tear-out force: 54.8 kN

Tear-out force backhoe: 63.4 kN

Max. Reach horizontal: 5.65 m

Dredging depth: 4.28 m

Max. discharge height: 2.8 m

Travel speed: 40 km/h

Engine manuf.: Caterpillar

Engine type: C3.4B

Engine power: 55 kW

Displacement: 3.4 l

Cylinder bore x stroke: 99x110 mm

Emission level: Stage IIIB

More technical details, like: bucket capacity backhoe, model series, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, backhoe type, telematics available, platform, engine manufacturer, engine model, aspiration, diesel oxidation catalyst, diesel particulate filter, selective catalytic reduction, rated speed, engine output - net, engine output - gross, torque rated speed, torque, transmission type, number of travel speeds, drive - 2wd / 4wd, service brake type, length - roading, height - over cab, maximum height, width, shovel quick-hitch, backhoe quick-hitch, width - standard shovel, stabiliser type, maximum dig depth - longest dipper, dig depth - sae, dig depth - sae retracted dipper, dig depth - sae extended dipper, reach from slew pivot - non-extending dipper, reach from slew pivot - retracted dipper, reach from slew pivot - extended dipper, loading height - non-extending dipper, loading height - retracted dipper, loading height - extended dipper, dump height - general purpose, dump angle - general purpose, dump height - multi-purpose, dump angle - multi-purpose, fuel tank, shovel capacity - standard general purpose, shovel capacity - multi-purpose, bucket tearout - non-extending dipper, dipper tearout - non-extending dipper, shovel breakout - general purpose, shovel breakout - multi-purpose, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: No
Clamshell: No
Forklift utility: No
Grabber: No
Diesel particulate filter: No
Aircondition: No

Download specalog and datasheets (PDF)

Caterpillar 427F2 FAQ

When was the Caterpillar 427F2 manufactured?

The Caterpillar 427F2 was manufactured from 2013 to 2019.

How much does the Caterpillar 427F2 backhoe loader weigh?

The Caterpillar 427F2 backhoe loader weighs 8.11 tons.

What are the transport dimensions of the Caterpillar 427F2 backhoe loader?

The Caterpillar 427F2 has a transport length of 5.7 meters, a transport width of 2.35 meters, and a transport height of 3.78 meters.

What is the travel speed of the Caterpillar 427F2 backhoe loader?

The Caterpillar 427F2 backhoe loader has a travel speed of 40 km/h.

What are the undercarriage specifications of the Caterpillar 427F2 backhoe loader?

The Caterpillar 427F2 features an all-wheel drive system with standard tyres sized Front: 12.5/80-18 and Rear: 16.9-28.

What are the excavation performance specifications of the Caterpillar 427F2 backhoe loader?

The Caterpillar 427F2 has a dredging depth of 4.28 meters and a maximum horizontal reach of 5.65 meters.

What are the tear-out forces of the Caterpillar 427F2 backhoe loader?

The Caterpillar 427F2 has a tear-out force of 54.8 kN and a backhoe tear-out force of 63.4 kN.

What is the maximum discharge height of the Caterpillar 427F2?

The Caterpillar 427F2 has a maximum discharge height of 2.8 meters.

What are the specifications of the primary work tool on the Caterpillar 427F2 backhoe loader?

The primary work tool of the Caterpillar 427F2 backhoe loader has a bucket capacity of 1.03 cubic meters and a bucket width of 2.41 meters.
