426F2 Caterpillar 426F2 Specifications & Technical Data (2017—2026)

The Caterpillar 426F2 is a backhoe loader that has been manufactured since 2017. It has a weight of 7.99 tons and a transport leng…

The Caterpillar 426F2 is a backhoe loader that has been manufactured since 2017. It has a weight of 7.99 tons and a transport length of 5.678 meters. The bucket capacity is 1.05 cubic meters, and it has a tear-out force of 54.46 kilonewtons. The dredging depth is 4.709 meters, and the bucket width is 2.262 meters. The maximum discharge height is 2.733 meters, and the maximum reach horizontal is 5.609 meters. It has a travel speed of 40 kilometers per hour. The transport width is 2.346 meters, and the transport height is 3.757 meters. The tear-out force for the backhoe is 57.2 kilonewtons. It is equipped with outrigger stabilizers.

426F2

Years of manufacture: 2017—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 426F2 Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 7.99 t

Standard tyres: 12.5/80-18/16.9-28

Bucket width: 2.262 m

Bucket capacity: 1.05 m³

Drive: A/H

Transport length: 5.678 m

Transport width: 2.346 m

Transport height: 3.757 m

Tear-out force: 54.46 kN

Tear-out force backhoe: 57.2 kN

Max. Reach horizontal: 5.609 m

Dredging depth: 4.709 m

Max. discharge height: 2.733 m

Travel speed: 40 km/h

Engine manuf.: Caterpillar

Engine type: 3054C

Engine power: 68.5 kW

Displacement: 4.4 l

Revolutions at max torque: 1400 rpm

Max. torque: 394 Nm

Cylinder bore x stroke: 105x127 mm

Emission level: EU Stage II

More technical details, like: bucket capacity backhoe, model series, dimension lxwxh, no. of cylinders are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: Yes
Clamshell: No
Forklift utility: No
Grabber: No
Diesel particulate filter: No
Aircondition: No

Download specalog and datasheets (PDF)

Caterpillar 426F2 FAQ

When was the Caterpillar 426F2 backhoe loader manufactured?

The Caterpillar 426F2 backhoe loader was first produced in 2017.

How much does the Caterpillar 426F2 backhoe loader weigh?

The Caterpillar 426F2 backhoe loader weighs 7.99 tons.

What are the transport dimensions of the Caterpillar 426F2 backhoe loader?

The Caterpillar 426F2 has a transport length of 5.68 meters, a transport width of 2.35 meters, and a transport height of 3.76 meters.

What is the travel speed of the Caterpillar 426F2 backhoe loader?

The Caterpillar 426F2 backhoe loader has a travel speed of 40 km/h.

What are the undercarriage specifications of the Caterpillar 426F2 backhoe loader?

The Caterpillar 426F2 has all-wheel drive and rear wheel drive and is equipped with standard tyres sized 12.5/80-18 and 16.9-28.

What is the excavation performance of the Caterpillar 426F2 backhoe loader?

The Caterpillar 426F2 backhoe loader has a dredging depth of 4.709 meters and a maximum horizontal reach of 5.609 meters.

What are the tear-out forces of the Caterpillar 426F2 backhoe loader?

The Caterpillar 426F2 has a tear-out force of 54.46 kN and a backhoe tear-out force of 57.2 kN.

What is the maximum discharge height of the Caterpillar 426F2?

The Caterpillar 426F2 has a maximum discharge height of 2.73 meters.

What are the bucket specifications of the Caterpillar 426F2 backhoe loader?

The Caterpillar 426F2 backhoe loader has a bucket capacity of 1.05 cubic meters and a bucket width of 2.26 meters.
