Lectura specs Construction machinery Backhoe Loaders Backhoe Loaders Caterpillar Caterpillar 424B2 specifications

Technical specs - 424B2 Caterpillar

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight 7.99 t
Standard tyres 12.5/80-18/16.9-28
Bucket width 2.262 m
Bucket capacity 1.05 m³
Drive A
Transport length 5.678 m
Transport width 2.346 m
Transport height 3.757 m
Tear-out force 54.46 kN
Tear-out force backhoe 57.22 kN
Max. Reach horizontal 5.609 m
Dredging depth 4.709 m
Max. discharge height 2.733 m
Travel speed 40 km/h
Engine manuf. Caterpillar
Engine type C4.4
Engine power 68.5 kW
Engine power 93 HP
Displacement 4.4 l
Revolutions at max torque 1400 rpm
Max. torque 394 Nm
Cylinder bore x stroke 105x127 mm
Emission level Bharat Stage III
Bucket capacity backhoe ###
Dimension lxwxh ###
No. of cylinders ###
Weight ###

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

424B2 Caterpillar - Special equipment

  • Outrigger stabilisers
  • Clamshell
  • Forklift utility
  • Grabber
  • Diesel particulate filter
  • Aircondition

Download data sheets - Caterpillar 424B2

Reviews - Caterpillar 424B2

Can not compare with jcb

Caterpillar 424B2 user from

What do you think about this machine?

Sell your Caterpillar 424B2 for a good price

Receive the best purchase offer² within 48 hours¹ from the network of WeBuyHeavyMachines.com with over 1,000 international dealers.

Compare Caterpillar 424B2 with other models

Press 1 image

Caterpillar 424B2
