420 E Caterpillar 420 E Specifications & Technical Data (2008—2026)

The Caterpillar 420 E is a backhoe loader manufactured by Caterpillar since 2008. It has a weight of 11 tons and a transport lengt…

The Caterpillar 420 E is a backhoe loader manufactured by Caterpillar since 2008. It has a weight of 11 tons and a transport length of 7.29 meters. The bucket capacity is 0.96 cubic meters, with a tear-out force of 45.6 kilonewtons. It can dredge up to a depth of 4.36 meters and has a bucket width of 2.26 meters. The maximum discharge height is 2.57 meters, and it has a maximum reach horizontal of 6.72 meters. The travel speed of this backhoe loader is 40 kilometers per hour. It has a transport width of 2.44 meters and a transport height of 3.58 meters. The backhoe bucket capacity is 0 cubic meters, and it has a tear-out force of 61.7 kilonewtons.

420 E

Years of manufacture: 2008—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 420 E Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 11 t

Standard tyres: F: 11L-16 12PR F-3/R: 19.5L-24 12PR R4 ATU

Bucket width: 2.26 m

Bucket capacity: 0.96 m³

Bucket capacity backhoe: 0.08-0.29 m³

Transport length: 7.29 m

Transport width: 2.44 m

Transport height: 3.58 m

Tear-out force: 45.6 kN

Tear-out force backhoe: 61.7 kN

Max. Reach horizontal: 6.72 m

Dredging depth: 4.36 m

Max. discharge height: 2.57 m

Travel speed: 40 km/h

Engine manuf.: Caterpillar

Engine type: C4.4 Acert DIT

Engine power: 75 kW

Displacement: 4.4 l

Max. torque: 408 Nm

Cylinder bore x stroke: 105x127 mm

Emission level: Tier 3/Stage IIIA

More technical details, like: drive, model series, dimension lxwxh, revolutions at max torque, no. of cylinders are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: No
Clamshell: No
Forklift utility: No
Grabber: No
Diesel particulate filter: No
Aircondition: No

Download specalog and datasheets (PDF)

Caterpillar 420 E FAQ

When was the Caterpillar 420 E manufactured?

The Caterpillar 420 E was first produced in 2008.

How much does the Caterpillar 420 E backhoe loader weigh?

The Caterpillar 420 E backhoe loader weighs 11 tons.

What are the transport dimensions of the Caterpillar 420 E backhoe loader?

The Caterpillar 420 E has a transport length of 7.29 meters, a transport width of 2.44 meters, and a transport height of 3.58 meters.

What is the travel speed of the Caterpillar 420 E backhoe loader?

The Caterpillar 420 E backhoe loader has a travel speed of 40 km/h.

What are the undercarriage specifications of the Caterpillar 420 E backhoe loader?

The Caterpillar 420 E backhoe loader has standard tyres with front size 11L-16 12PR F-3 and rear size 19.5L-24 12PR R4 ATU.

What are the excavation performance specifications of the Caterpillar 420 E backhoe loader?

The Caterpillar 420 E backhoe loader has a dredging depth of 4.36 meters and a maximum horizontal reach of 6.72 meters.

What are the power ratings of the Caterpillar 420 E backhoe loader?

The Caterpillar 420 E has a tear-out force of 45.6 kN and a backhoe tear-out force of 61.7 kN.

What is the material handling capacity of the Caterpillar 420 E in terms of discharge height?

The Caterpillar 420 E has a maximum discharge height of 2.57 meters.

What are the specifications of the primary work tool bucket on the Caterpillar 420 E backhoe loader?

The primary work tool bucket on the Caterpillar 420 E has a capacity of 0.96 cubic meters and a width of 2.26 meters.
