851FX+ Case 851FX+ Specifications & Technical Data (2022—2026)

The Case 851FX+ is a backhoe loader manufactured by Case since 2022. It has a weight of 8.1 tons and a transport length of 3.06 me…

The Case 851FX+ is a backhoe loader manufactured by Case since 2022. It has a weight of 8.1 tons and a transport length of 3.06 meters. The bucket capacity is 1.2 cubic meters, with a tear-out force of 55.1 kilonewtons. It can dredge up to a depth of 4.7 meters and has a bucket width of 2.3 meters. The maximum discharge height is 2.86 meters, and it can reach a maximum horizontal distance of 5.9 meters. The travel speed is 39.2 kilometers per hour. The transport width is 2.27 meters, and the transport height is 3.85 meters. Additionally, it has a backhoe bucket capacity of 0.3 cubic meters and a tear-out force of 37.1 kilonewtons.

851FX+

Years of manufacture: 2022—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 851FX+ Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 8.1 t

Standard tyres: F: 9.0 x 16 – 16 PR / R: 16.9 x 28 – 12 PR

Bucket width: 2.3 m

Bucket capacity: 1.2 m³

Bucket capacity backhoe: 0.3 m³

Transport length: 3.06 m

Transport width: 2.27 m

Transport height: 3.85 m

Tear-out force: 55.1 kN

Tear-out force backhoe: 37.1 kN

Max. Reach horizontal: 5.9 m

Dredging depth: 4.7 m

Max. discharge height: 2.86 m

Travel speed: 39.2 km/h

Model series: FX

Engine manuf.: FPT

Engine type: F5BFL413A*W

Engine power: 72 kW

Displacement: 3.4 l

Max. torque: 459 Nm

Emission level: Tier 4B

More technical details, like: drive, dimension lxwxh, revolutions at max torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: No
Clamshell: No
Forklift utility: No
Grabber: No
Diesel particulate filter: No
Aircondition: No

Download datasheets (PDF)

851FX+ Case Specification for Asia Pacific (EN)

Case 851FX+ FAQ

When was the Case 851FX+ manufactured?

The Case 851FX+ was first produced in 2022.

How much does the Case 851FX+ backhoe loader weigh?

The Case 851FX+ backhoe loader weighs 8.1 tons.

What are the transport dimensions of the Case 851FX+ backhoe loader?

The Case 851FX+ has a transport length of 3.06 meters, a transport width of 2.27 meters, and a transport height of 3.85 meters.

What is the travel speed of the Case 851FX+ backhoe loader?

The Case 851FX+ backhoe loader has a travel speed of 39.2 km/h.

What are the undercarriage tyre specifications of the Case 851FX+ backhoe loader?

The Case 851FX+ is equipped with front tyres sized 9.0 x 16 u2013 16 PR and rear tyres sized 16.9 x 28 u2013 12 PR.

What is the excavation performance of the Case 851FX+ backhoe loader?

The Case 851FX+ backhoe loader has a dredging depth of 4.7 meters and a maximum horizontal reach of 5.9 meters.

What are the tear-out forces of the Case 851FX+ backhoe loader?

The Case 851FX+ has a tear-out force of 55.1 kN and a backhoe tear-out force of 37.1 kN.

What is the maximum discharge height of the Case 851FX+?

The Case 851FX+ has a maximum discharge height of 2.86 meters.

What are the primary work tool specifications of the Case 851FX+ backhoe loader?

The Case 851FX+ has a loader bucket capacity of 1.2 cubic meters with a width of 2.3 meters, and a backhoe bucket capacity of 0.3 cubic meters.
