851FX Case 851FX Specifications & Technical Data (2022—2026)

The Case 851FX is a backhoe loader manufactured by Case since 2022. It has a weight of 8.1 tons and a transport length of 6.06 met…

The Case 851FX is a backhoe loader manufactured by Case since 2022. It has a weight of 8.1 tons and a transport length of 6.06 meters. The bucket capacity is 1.2 cubic meters, with a tear-out force of 55.1 kilonewtons. It can dredge up to a depth of 4.7 meters and has a bucket width of 2.3 meters. The maximum discharge height is 2.86 meters, and it has a maximum reach horizontal of 5.9 meters. The travel speed of this backhoe loader is 39.2 kilometers per hour. It has a transport width of 2.27 meters and a transport height of 3.85 meters. The backhoe bucket capacity is 0.3 cubic meters, and it has a tear-out force of 37.1 kilonewtons.

851FX

Years of manufacture: 2022—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 851FX Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 8.1 t

Standard tyres: F: 9.0 x 16 – 16 PR / R: 16.9 x 28 – 12 PR

Bucket width: 2.3 m

Bucket capacity: 1.2 m³

Bucket capacity backhoe: 0.3 m³

Transport length: 6.06 m

Transport width: 2.27 m

Transport height: 3.85 m

Tear-out force: 55.1 kN

Tear-out force backhoe: 37.1 kN

Max. Reach horizontal: 5.9 m

Dredging depth: 4.7 m

Max. discharge height: 2.86 m

Travel speed: 39.2 km/h

Model series: FX

Engine manuf.: FPT

Engine type: F5BFL413A*W

Engine power: 72 kW

Displacement: 3.4 l

Max. torque: 459 Nm

Emission level: Tier 4B

More technical details, like: drive, dimension lxwxh, revolutions at max torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: No
Clamshell: No
Forklift utility: No
Grabber: No
Diesel particulate filter: No
Aircondition: No

Download datasheets (PDF)

851FX Case Specification for Asia Pacific (EN)

Case 851FX FAQ

When was the Case 851FX manufactured?

The Case 851FX was first produced in 2022.

How much does the Case 851FX backhoe loader weigh?

The Case 851FX backhoe loader weighs 8.1 tons.

What are the transport dimensions of the Case 851FX backhoe loader?

The Case 851FX has a transport length of 6.06 meters, a transport width of 2.27 meters, and a transport height of 3.85 meters.

What is the travel speed of the Case 851FX backhoe loader?

The Case 851FX backhoe loader has a travel speed of 39.2 km/h.

What are the undercarriage tyre specifications of the Case 851FX backhoe loader?

The Case 851FX backhoe loader has standard tyres sized Front: 9.0 x 16 u2013 16 PR and Rear: 16.9 x 28 u2013 12 PR.

What are the excavation performance specifications of the Case 851FX backhoe loader?

The Case 851FX backhoe loader has a dredging depth of 4.7 meters and a maximum horizontal reach of 5.9 meters.

What are the tear-out forces of the Case 851FX backhoe loader?

The Case 851FX has a tear-out force of 55.1 kN and a backhoe tear-out force of 37.1 kN.

What is the material handling capacity of the Case 851FX in terms of discharge height?

The Case 851FX has a maximum discharge height of 2.86 meters.

What are the specifications of the primary work tools on the Case 851FX backhoe loader?

The Case 851FX features a front loader bucket with a capacity of 1.2 cubic meters and a width of 2.3 meters, and a backhoe bucket with a capacity of 0.3 cubic meters.
