851EX Case 851EX Specifications & Technical Data (2021—2026)

The Case 851EX is a backhoe loader manufactured by Case since 2021. It has a weight of 8.23 tons and a bucket capacity of 1.2 cubi…

The Case 851EX is a backhoe loader manufactured by Case since 2021. It has a weight of 8.23 tons and a bucket capacity of 1.2 cubic meters. The tear-out force of this machine is 64 kilonewtons, and it can dredge up to a depth of 4.7 meters. The bucket width is 2.3 meters, and it has a maximum discharge height of 3.3 meters. The maximum reach horizontal is 5.9 meters, and the travel speed is 39.2 kilometers per hour. It has a transport width of 2.8 meters and a transport height of 3.8 meters. The backhoe bucket capacity is 0.3 cubic meters, and it has a tear-out force of 55 kilonewtons.

Backhoe Loaders Case 851EX
Backhoe Loaders Case 851EX
Backhoe Loaders Case 851EX
Backhoe Loaders Case 851EX

Technical specs - 851EX Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
8.23 t
Standard tyres
F: 9.0x16 - 16 PR / R: 16.9x28 - 12 PR
Bucket width
2.3 m
Bucket capacity
1.2 m³
Bucket capacity backhoe
0.3 m³
Transport width
2.8 m
Transport height
3.8 m
Tear-out force
64 kN
Tear-out force backhoe
55 kN
Max. Reach horizontal
5.9 m
Dredging depth
4.7 m
Max. discharge height
3.3 m
Travel speed
39.2 km/h
Model series
EX
Engine manuf.
FPT
Engine type
S8000
Engine power
72 kW
Displacement
3.9 l
Revolutions at max torque
1300 rpm
Max. torque
420 Nm
Cylinder bore x stroke
104x115 mm

More technical details, like: drive, transport length, dimension lxwxh, no. of cylinders, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers
No
Clamshell
No
Forklift utility
No
Grabber
No
Diesel particulate filter
No
Aircondition
No

Download datasheets (PDF)

Case 851EX FAQ

When was the Case 851EX manufactured?

The Case 851EX was first produced in 2021.

How much does the Case 851EX backhoe loader weigh?

The Case 851EX backhoe loader weighs 8.23 tons.

What are the transport dimensions of the Case 851EX backhoe loader?

The Case 851EX has a transport width of 2.8 meters and a transport height of 3.8 meters.

What is the travel speed of the Case 851EX backhoe loader?

The Case 851EX backhoe loader has a travel speed of 39.2 km/h.

What are the undercarriage specifications of the Case 851EX backhoe loader?

The Case 851EX backhoe loader has standard tyres with front size 9.0x16 - 16 PR and rear size 16.9x28 - 12 PR.

What is the excavation performance of the Case 851EX backhoe loader?

The Case 851EX has a dredging depth of 4.7 meters and a maximum horizontal reach of 5.9 meters.

What are the tear-out forces of the Case 851EX backhoe loader?

The Case 851EX has a tear-out force of 64 kN and a backhoe tear-out force of 55 kN.

What is the material handling capacity of the Case 851EX in terms of discharge height?

The Case 851EX has a maximum discharge height of 3.3 meters.

What are the specifications of the primary work tools on the Case 851EX backhoe loader?

The Case 851EX features a front loader bucket with a capacity of 1.2 cubic meters and a width of 2.3 meters, as well as a backhoe bucket with a capacity of 0.3 cubic meters.
