590ST T4 Case 590ST T4 Specifications & Technical Data (2012—2017)

The Case 590ST T4 is a backhoe loader manufactured by Case from 2012 to 2017. It has a weight of 8.12 tons and a transport length …

The Case 590ST T4 is a backhoe loader manufactured by Case from 2012 to 2017. It has a weight of 8.12 tons and a transport length of 5.77 meters. The bucket capacity is 1 cubic meter, with a tear-out force of 40.62 kilonewtons. It can dredge up to a depth of 4.67 meters and has a bucket width of 2.25 meters. The travel speed of this machine is 40 kilometers per hour. It has a transport width of 2.43 meters and a transport height of 3.9 meters. The backhoe has a bucket capacity of 0.32 cubic meters and a tear-out force of 53.26 kilonewtons.

590ST T4

Years of manufacture: 2012—2017

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 590ST T4 Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 8.12 t

Standard tyres: 16.9-28

Bucket width: 2.25 m

Bucket capacity: 1 m³

Bucket capacity backhoe: 0.32 m³

Drive: A

Transport length: 5.77 m

Transport width: 2.43 m

Transport height: 3.9 m

Tear-out force: 40.62 kN

Tear-out force backhoe: 53.26 kN

Dredging depth: 4.67 m

Travel speed: 40 km/h

Model series: ST

Engine manuf.: CNH

Engine type: 445TA-EGH

Engine power: 82 kW

Displacement: 4.5 l

Revolutions at max torque: 1400 rpm

Emission level: TIER 4i

More technical details, like: max. reach horizontal, max. discharge height, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, backhoe type, telematics available, platform, engine manufacturer, engine model, emission rating, aspiration, rated speed, engine output - net, torque, transmission type, number of travel speeds, drive - 2wd / 4wd, service brake type, length - roading, height - over cab, maximum height, width, stabiliser type, maximum dig depth - longest dipper, reach from slew pivot - non-extending dipper, reach from slew pivot - retracted dipper, reach from slew pivot - extended dipper, loading height - non-extending dipper, loading height - retracted dipper, loading height - extended dipper, dump height - general purpose, dump angle - general purpose, dump height - multi-purpose, dump angle - multi-purpose, fuel tank, shovel capacity - standard general purpose, bucket tearout - non-extending dipper, dipper tearout - non-extending dipper, shovel breakout - general purpose, shovel breakout - multi-purpose, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: No
Clamshell: No
Forklift utility: No
Grabber: No
Diesel particulate filter: No
Aircondition: No

Download datasheets (PDF)

590ST T4 Case Specification for Europe (EN)

Case 590ST T4 FAQ

When was the Case 590ST T4 manufactured?

The Case 590ST T4 was manufactured from 2012 to 2017.

How much does the Case 590ST T4 backhoe loader weigh?

The Case 590ST T4 backhoe loader weighs 8.12 tons.

What are the transport dimensions of the Case 590ST T4 backhoe loader?

The Case 590ST T4 has a transport length of 5.77 meters, a transport width of 2.43 meters, and a transport height of 3.9 meters.

What is the travel speed of the Case 590ST T4 backhoe loader?

The Case 590ST T4 backhoe loader has a travel speed of 40 km/h.

What are the undercarriage specifications of the Case 590ST T4 backhoe loader?

The Case 590ST T4 backhoe loader features an all-wheel drive system and standard tyres sized 16.9-28.

What is the dredging depth of the Case 590ST T4 backhoe loader?

The Case 590ST T4 backhoe loader has a dredging depth of 4.67 meters.

What are the tear-out forces of the Case 590ST T4 backhoe loader?

The Case 590ST T4 has a tear-out force of 40.62 kN and a backhoe tear-out force of 53.26 kN.

What are the specifications of the primary work tools on the Case 590ST T4 backhoe loader?

The Case 590ST T4 features a front bucket with a capacity of 1 cubic meter and a width of 2.25 meters, and a backhoe bucket with a capacity of 0.32 cubic meters.
