590 Turbo Case 590 Turbo Specifications & Technical Data (1991—1995)

The Case 590 Turbo is a backhoe loader manufactured by Case since 1993. It has a weight of 7.139 tons and a transport length of 7.…

The Case 590 Turbo is a backhoe loader manufactured by Case since 1993. It has a weight of 7.139 tons and a transport length of 7.16 meters. The bucket capacity is 0.96 cubic meters, with a dredging depth of 4.76 meters and a bucket width of 2.29 meters. The maximum reach horizontal is 7.06 meters, and it has a travel speed of 40 km/h. The transport width is 2.22 meters, and the transport height is 2.64 meters. Additionally, it has a bucket capacity of 0.08 cubic meters for the backhoe.

Backhoe Loaders Case 590 Turbo

Technical specs - 590 Turbo Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
7.14 t
Standard tyres
14.9x24
Bucket width
2.29 m
Bucket capacity
0.96 m³
Bucket capacity backhoe
0.08 m³
Transport length
7.16 m
Transport width
2.22 m
Transport height
2.64 m
Max. Reach horizontal
7.06 m
Dredging depth
4.76 m
Travel speed
40 km/h
Model series
Turbo
Engine manuf.
Case
Engine type
4T 390
Engine power
69 kW
Displacement
3.9 l
Max. torque
351 Nm
No. of cylinders
4
Cylinder bore x stroke
102x120 mm

More technical details, like: drive, tear-out force, tear-out force backhoe, max. discharge height, dimension lxwxh, revolutions at max torque, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers
No
Clamshell
No
Forklift utility
No
Grabber
No
Diesel particulate filter
No
Aircondition
No

Download datasheets (PDF)

Case 590 Turbo FAQ

When was the Case 590 Turbo manufactured?

The Case 590 Turbo was manufactured from 1991 to 1995.

How much does the Case 590 Turbo backhoe loader weigh?

The Case 590 Turbo backhoe loader weighs 7.14 tons.

What are the transport dimensions of the Case 590 Turbo backhoe loader?

The Case 590 Turbo has a transport length of 7.16 meters, a transport width of 2.22 meters, and a transport height of 2.64 meters.

What is the travel speed of the Case 590 Turbo backhoe loader?

The Case 590 Turbo backhoe loader has a travel speed of 40 km/h.

What is the standard tyre size of the Case 590 Turbo backhoe loader?

The Case 590 Turbo backhoe loader has standard tyres sized 14.9x24.

What are the dredging depth and maximum horizontal reach of the Case 590 Turbo backhoe loader?

The Case 590 Turbo has a dredging depth of 4.76 meters and a maximum horizontal reach of 7.06 meters.

What are the primary bucket specifications of the Case 590 Turbo backhoe loader?

The Case 590 Turbo has a front bucket capacity of 0.96 cubic meters, a bucket width of 2.29 meters, and a backhoe bucket capacity of 0.08 cubic meters.
