590 Super R Case 590 Super R Specifications & Technical Data (2004—2026)

The Case 590 Super R is a backhoe loader manufactured by Case since 2004. It has a weight of 8.14 tons and a transport length of 5…

The Case 590 Super R is a backhoe loader manufactured by Case since 2004. It has a weight of 8.14 tons and a transport length of 5.77 meters. The bucket capacity is 1 cubic meter, with a tear-out force of 35.65 kilonewtons. It can dredge up to a depth of 5.799 meters and has a bucket width of 2.25 meters. The maximum discharge height is 4.645 meters, and it can reach horizontally up to 6.992 meters. The travel speed of this machine is 46.4 kilometers per hour. It has a transport width of 2.23 meters and a transport height of 3.9 meters. The tear-out force of the backhoe is 56.03 kilonewtons. Additionally, it is equipped with special features such as a forklift utility and outrigger stabilizers.

Backhoe Loaders Case 590 Super R

Technical specs - 590 Super R Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
8.14 t
Standard tyres
16.9x28
Bucket width
2.25 m
Bucket capacity
1 m³
Transport length
5.77 m
Transport width
2.23 m
Transport height
3.9 m
Tear-out force
35.65 kN
Tear-out force backhoe
56.03 kN
Max. Reach horizontal
6.992 m
Dredging depth
5.799 m
Max. discharge height
4.645 m
Travel speed
46.4 km/h
Model series
Super
Engine manuf.
Case
Engine type
NEF Family III 445TA/EGH
Engine power
82 kW
Displacement
4.5 l
Max. torque
516 Nm
No. of cylinders
4
Cylinder bore x stroke
104x132 mm
Emission level
Tier 3

More technical details, like: bucket capacity backhoe, drive, dimension lxwxh, revolutions at max torque are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers
Yes
Clamshell
No
Forklift utility
Yes
Grabber
No
Diesel particulate filter
No
Aircondition
No

Download datasheets (PDF)

Case 590 Super R FAQ

When was the Case 590 Super R manufactured?

The Case 590 Super R was first produced in 2004.

How much does the Case 590 Super R backhoe loader weigh?

The Case 590 Super R backhoe loader weighs 8.14 tons.

What are the transport dimensions of the Case 590 Super R backhoe loader?

The Case 590 Super R has a transport length of 5.77 meters, a transport width of 2.23 meters, and a transport height of 3.9 meters.

What is the travel speed of the Case 590 Super R backhoe loader?

The Case 590 Super R backhoe loader has a travel speed of 46.4 km/h.

What is the standard tyre size of the Case 590 Super R backhoe loader?

The Case 590 Super R backhoe loader has standard tyres sized 16.9x28.

What is the excavation performance of the Case 590 Super R backhoe loader?

The Case 590 Super R has a dredging depth of 5.799 meters and a maximum horizontal reach of 6.992 meters.

What are the tear-out forces of the Case 590 Super R backhoe loader?

The Case 590 Super R has a tear-out force of 35.65 kN and a backhoe tear-out force of 56.03 kN.

What is the material handling capacity of the Case 590 Super R in terms of discharge height?

The Case 590 Super R has a maximum discharge height of 4.65 meters.

What are the specifications of the primary work tool bucket on the Case 590 Super R?

The primary work tool bucket of the Case 590 Super R has a capacity of 1 cubic meter and a width of 2.25 meters.
