Case 580ST Backhoe Loader Specs & Dimensions (2012 - 2017)

Technical specs - 580ST Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 8.05 t

Standard tyres: 16.9-28

Bucket width: 2.25 m

Bucket capacity: 1 m³

Drive: A

Transport length: 5.77 m

Transport width: 2.43 m

Transport height: 3.9 m

Model series: ST

Engine manuf.: CNH

Engine type: 445TA-EEA

Engine power: 72 kW

Displacement: 4.5 l

Revolutions at max torque: 1400 rpm

Emission level: TIER 4i

More technical details, like: bucket capacity backhoe, tear-out force, tear-out force backhoe, max. reach horizontal, dredging depth, max. discharge height, travel speed, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, backhoe type...

More technical details, like: bucket capacity backhoe, tear-out force, tear-out force backhoe, max. reach horizontal, dredging depth, max. discharge height, travel speed, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, backhoe type, telematics available, platform, engine manufacturer, engine model, aspiration, charged air cooling, diesel particulate filter, selective catalytic reduction, rated speed, engine output - gross, torque rated speed, torque, transmission type, number of travel speeds, drive - 2wd / 4wd, service brake type, length - roading, height - over cab, width, ground clearance, shovel quick-hitch, backhoe quick-hitch, width - standard shovel, stabiliser type, maximum dig depth - longest dipper, reach from slew pivot - non-extending dipper, reach from slew pivot - retracted dipper, reach from slew pivot - extended dipper, loading height - non-extending dipper, loading height - retracted dipper, loading height - extended dipper, dump height - general purpose, dump angle - general purpose, dump height - multi-purpose, dump angle - multi-purpose, fuel tank, shovel capacity - standard general purpose, shovel capacity - multi-purpose, bucket tearout - non-extending dipper, dipper tearout - non-extending dipper, shovel breakout - general purpose, shovel breakout - multi-purpose, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: No
Clamshell: No
Forklift utility: No
Grabber: No
Diesel particulate filter: No
Aircondition: No

Download datasheets (PDF)

Case 580ST FAQ

When was the Case 580ST manufactured?

The Case 580ST was manufactured from 2012 to 2017.

How much does the Case 580ST backhoe loader weigh?

The Case 580ST backhoe loader weighs 8.05 tons.

What are the transport dimensions of the Case 580ST backhoe loader?

The Case 580ST backhoe loader has a transport length of 5.77 meters, a transport width of 2.43 meters, and a transport height of 3.9 meters.

What are the undercarriage specifications of the Case 580ST backhoe loader?

The Case 580ST backhoe loader features an all-wheel drive system and standard tyres sized 16.9-28.

What are the bucket specifications of the Case 580ST backhoe loader?

The Case 580ST backhoe loader has a bucket capacity of 1 cubic meter and a bucket width of 2.25 meters.

How much is a Case 580STu00a0 Backhoe loader (2012u20132017) worth?

The residual value of the Case 580STu00a0 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
