580ST Case 580ST Specifications & Technical Data (2009—2014)

Model rating: 7,50 / 10

The Case 580ST Backhoe Loader, manufactured from 2009 to 2014, is a construction machine with a weight of 8.05 tons. It has a tran…

The Case 580ST Backhoe Loader, manufactured from 2009 to 2014, is a construction machine with a weight of 8.05 tons. It has a transport length of 5.77 meters and a bucket capacity of 1 cubic meter. The dredging depth of this machine is 4.369 meters, while the bucket width measures 2.25 meters. The transport width is 2.43 meters, and the transport height is 3.9 meters.

580ST

Years of manufacture: 2009—2014

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 580ST Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 8.05 t

Bucket width: 2.25 m

Bucket capacity: 1 m³

Drive: A

Transport length: 5.77 m

Transport width: 2.43 m

Transport height: 3.9 m

Dredging depth: 4.369 m

Model series: ST

Engine manuf.: CNH

Engine type: F4GE9484C*J

Engine power: 72 kW

Displacement: 4.5 l

Revolutions at max torque: 1400 rpm

More technical details, like: standard tyres, bucket capacity backhoe, tear-out force, tear-out force backhoe, max. reach horizontal, max. discharge height, travel speed, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, backhoe type, telematics available, platform, engine manufacturer, engine model, aspiration, charged air cooling, diesel particulate filter, selective catalytic reduction, rated speed, engine output - gross, torque rated speed, torque, transmission type, number of travel speeds, drive - 2wd / 4wd, service brake type, length - roading, height - over cab, width, ground clearance, shovel quick-hitch, backhoe quick-hitch, width - standard shovel, stabiliser type, maximum dig depth - longest dipper, reach from slew pivot - non-extending dipper, reach from slew pivot - retracted dipper, reach from slew pivot - extended dipper, loading height - non-extending dipper, loading height - retracted dipper, loading height - extended dipper, dump height - general purpose, dump angle - general purpose, dump height - multi-purpose, dump angle - multi-purpose, fuel tank, shovel capacity - standard general purpose, shovel capacity - multi-purpose, bucket tearout - non-extending dipper, dipper tearout - non-extending dipper, shovel breakout - general purpose, shovel breakout - multi-purpose, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: No
Clamshell: No
Forklift utility: No
Grabber: No
Diesel particulate filter: No
Aircondition: No

Download datasheets (PDF)

Case 580ST FAQ

When was the Case 580ST manufactured?

The Case 580ST was manufactured from 2009 to 2014.

How much does the Case 580ST backhoe loader weigh?

The Case 580ST backhoe loader weighs 8.05 tons.

What are the transport dimensions of the Case 580ST backhoe loader?

The Case 580ST has a transport length of 5.77 meters, a transport width of 2.43 meters, and a transport height of 3.9 meters.

What is the undercarriage drive type of the Case 580ST?

The Case 580ST has all-wheel drive.

What is the dredging depth of the Case 580ST backhoe loader?

The Case 580ST backhoe loader has a dredging depth of 4.369 meters.

What are the specifications of the primary work tool bucket on the Case 580ST backhoe loader?

The primary work tool bucket of the Case 580ST has a capacity of 1 cubic meter and a width of 2.25 meters.
