580N EP Case 580N EP Specifications & Technical Data (2021—2026)

The Case 580N EP is a backhoe loader manufactured by Case since 2021. It has a weight of 7.17 tons and a transport length of 6.93 …

The Case 580N EP is a backhoe loader manufactured by Case since 2021. It has a weight of 7.17 tons and a transport length of 6.93 meters. The bucket capacity is 0.8 cubic meters, with a tear-out force of 42.73 kilonewtons. The dredging depth is 5.63 meters, and the bucket width is 2.08 meters. The maximum discharge height is 2.63 meters, and the maximum reach horizontal is 6.68 meters. It has a travel speed of 34.3 kilometers per hour. The transport width is 2.17 meters, and the transport height is 2.72 meters. The backhoe bucket capacity is 0.18 cubic meters, with a tear-out force of 51.2 kilonewtons.

580N EP

Years of manufacture: 2021—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 580N EP Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 7.17 t

Standard tyres: 19.5 L x 24.0

Bucket width: 2.08 m

Bucket capacity: 0.8 m³

Bucket capacity backhoe: 0.18 m³

Transport length: 6.93 m

Transport width: 2.17 m

Transport height: 2.72 m

Tear-out force: 42.73 kN

Tear-out force backhoe: 51.2 kN

Max. Reach horizontal: 6.68 m

Dredging depth: 5.63 m

Max. discharge height: 2.63 m

Travel speed: 34.3 km/h

Model series: N

Engine manuf.: FPT

Engine type: F5HFL463D

Engine power: 51 kW

Displacement: 3.4 l

Revolutions at max torque: 1400 rpm

Max. torque: 316 Nm

No. of cylinders: 4

Cylinder bore x stroke: 99x110 mm

Emission level: Tier 4F

More technical details, like: drive, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: No
Clamshell: No
Forklift utility: No
Grabber: No
Diesel particulate filter: No
Aircondition: No

Download datasheets (PDF)

Case 580N EP FAQ

When was the Case 580N EP manufactured?

The Case 580N EP was first produced in 2021.

How much does the Case 580N EP backhoe loader weigh?

The Case 580N EP backhoe loader weighs 7.17 tons.

What are the transport dimensions of the Case 580N EP backhoe loader?

The Case 580N EP has a transport length of 6.93 meters, a transport width of 2.17 meters, and a transport height of 2.72 meters.

What is the travel speed of the Case 580N EP backhoe loader?

The Case 580N EP backhoe loader has a travel speed of 34.3 km/h.

What are the undercarriage specifications of the Case 580N EP backhoe loader?

The Case 580N EP backhoe loader is equipped with standard tyres sized 19.5 L x 24.0.

What are the excavation performance specifications of the Case 580N EP backhoe loader?

The Case 580N EP has a dredging depth of 5.63 meters and a maximum horizontal reach of 6.68 meters.

What are the tear-out force specifications of the Case 580N EP backhoe loader?

The Case 580N EP has a tear-out force of 42.73 kN and a tear-out force for the backhoe of 51.2 kN.

What is the maximum discharge height of the Case 580N EP backhoe loader?

The Case 580N EP backhoe loader has a maximum discharge height of 2.63 meters.

What are the primary work tool specifications of the Case 580N EP backhoe loader?

The Case 580N EP features a bucket capacity of 0.8 cubic meters, a bucket width of 2.08 meters, and a backhoe bucket capacity of 0.18 cubic meters.
