RX3 Chicago Pneumatic RX3 Specifications & Technical Data (2017—2022)

Weight: 150kg – No. of Blows: 15001/min – Carrying device: 2-4.5t – Total length: 530mm – Tool Ø: 52mm – Oil flow: 50l/min

Attachments Hydraulic Breakers Chicago Pneumatic RX3

Technical specs - RX3 Chicago Pneumatic

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
150 kg
No. of Blows
1500 1/min
Carrying device
2-4.5 t
Total length
530 mm
Tool Ø
52 mm
Oil flow
50 l/min
Operating pressure
140 bar
Model series
Light

Basic model without chisel and without adapter for excavator

Special equipment

Central lubrication
No
silenced
Yes
Subaqueous equipment
No
Quick hitch mech.
No

Download datasheets (PDF)

Chicago Pneumatic RX3 overview

Chicago Pneumatic RX3 features overview

Chicago Pneumatic RX Hydraulic Breakers

There's no time for downtime on the job. That's why Chicago Pneumatic RX hydraulic breakers are built to power through the toughest tasks day in and day out, year after year. The smart design has fewer components with only two moving parts for easy maintenance, long service life and quiet operation.


Operating cycle

Heavy Hydraulic Breakers

Applications: Used in medium and heavy industrial demolition, building renovation, road construction, rock excavation, quarrying. Power control plus enables the operator to adjust the operation mode of the breaker to the application to optimize productivity. It's a combined stroke length and start-up mode switching valve that the operator can change in the field without opening the hydraulic circuit. The active ventilation port protects the carrier and breaker by reducing dust intake into the hydraulic circuit. Double tool retainer bars ensure optimal working tool guidance. The reinforced breaker box design provides higher wear protection with additional rock claws. Optional features increase service life with the automatic lubrication device CP-Lube and Dust Wiper.
