MSB MSGG - 4000
- Grabber capacity:
- 0.9 m³
- Closing force:
- 70 kN
- Height:
- 1869 mm
- Width:
- 1502 mm
MSGG - 4000 MSB MSGG - 4000 Specifications & Technical Data (2001—2003)
Technical specs - MSGG - 4000 MSB
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Grabber capacity
- 0.9 m³
- Closing force
- 70 kN
- Height
- 1869 mm
- Width
- 1502 mm
- Opening width
- 2038 mm
- Max. pressure
- 350 bar
- Weight
- 1.68 t
- Model series
- MSGG
Basic model without hoselines and adapter for excavator
Special equipment
- endless rotation
-
No
- Hydr. grabber rotating mechanism
-
No
- Piston rod protections
-
No
- Quick hitch mech.
-
No
Download datasheets (PDF)
