Technical specs - A40GFS Volvo
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 29.9 t
- Standard tyres
- 29.5 R 25
- Dump capacity
- 18.4 m³
- Travel speed
- 57 km/h
- Net load
- 39 t
- Transport length
- 11.263 m
- Transport width
- 3.403 m
- Transport height
- 3.599 m
- Turning radius outside
- 8.957 m
- Loading height
- 3.132 m
- Model series
- A
- Engine manuf.
- Volvo
- Engine type
- D13J
- Engine power
- 350 kW
- Displacement
- 12.8 l
- Revolutions at max torque
- 1900 rpm
- Max. torque
- 2500 Nm
- No. of cylinders
- 6
- Emission level
- Tier 4 f
Special equipment
- Diesel particulate filter
-
No
- Central lubrication
-
No
- Heated dump body
-
No
- Tailgate
-
No
- Aircondition
-
No
