Technical specs - A40 Volvo
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 31.3 t
- Standard tyres
- 29.5 R 25
- Dump capacity
- 24 m³
- Travel speed
- 57 km/h
- Net load
- 39 t
- Transport length
- 11.261 m
- Transport width
- 3.401 m
- Transport height
- 3.626 m
- Turning radius outside
- 9.144 m
- Loading height
- 3.142 m
- Model series
- A
- Engine manuf.
- Volvo
- Engine type
- D13F
- Engine power
- 350 kW
- Displacement
- 12.8 l
- Revolutions at max torque
- 1800 rpm
- Max. torque
- 2525/1050 Nm
- No. of cylinders
- 6
- Emission level
- II
More technical details, like: dimension lxwxh, cylinder bore x stroke are available in the full technical specs.
Special equipment
- Diesel particulate filter
-
No
- Central lubrication
-
No
- Heated dump body
-
No
- Tailgate
-
No
- Aircondition
-
No
