MT 25 Moxy MT 25 Specifications & Technical Data (2002—2008)

Moxy is the manufacturer of the articulated dump truck model MT 25. Find and download detailed specs and data sheets for this mach…

Moxy is the manufacturer of the articulated dump truck model MT 25. Find and download detailed specs and data sheets for this machine here.

Equipped with a powerful Scania engine, this MT 25 21t machine can provide 234kW or 313 horse power for the articulated dump truck. The MT 25 is categorised in the medium sized machine segment in the articulated dump trucks category.

The Moxy MT 25 has been equipped and sold with Central lubrication and Aircondition. It has been sold without air Bin heating, Diesel particulate filter and Tailgate as of 2008. There are more detailed specifications and machine descriptions available in the original Moxy MT 25 specs data sheet.

This model can be acquired for a list price between €282000 and €358000. Production of the MT 25 stopped in 2008. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

Moxy currently produces other articulated dump trucks, which range from up to - the most visited on LECTURA Specs are. Want more detailed specifications? Download the latest Moxy MT 25 specs data sheet on LECTURA Specs today!

Articulated Dump Trucks Moxy MT 25

Technical specs - MT 25 Moxy

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
21 t
Standard tyres
20.5-25
Dump capacity
13.7 m³
Travel speed
46 km/h
Net load
22.6 t
Loading height
2.75 m
Engine manuf.
Scania
Engine type
DC 9
Engine power
234 kW
Displacement
8.9 l
Revolutions at max torque
2200 rpm

More technical details, like: transport length, transport width, transport height, turning radius outside, model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, engine manufacturer, engine model...

More technical details, like: transport length, transport width, transport height, turning radius outside, model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, engine manufacturer, engine model, engine output - gross, drive configuration, transmission type, transmission manufacturer, tyre - size, length - overall, height - max, ground clearance, width - over tyres, width - transport, width - operating, loading height, full dump height, hoist - type, hoist - angle, articulation angle, turning radius - outside, turning radius - inside, fuel tank, heaped capacity, cycle time - raise, net weight, payload, gross weight are available in the full technical specs.

Special equipment

Diesel particulate filter
No
Central lubrication
Yes
Heated dump body
No
Tailgate
No
Aircondition
Yes

Moxy MT 25 FAQ

When was the Moxy MT 25 manufactured?

The Moxy MT 25 was manufactured from 2002 to 2008.

How much does the Moxy MT 25 weigh?

The Moxy MT 25 weighs 21 tons.

What is the travel speed of the Moxy MT 25 articulated dump truck?

The Moxy MT 25 articulated dump truck has a travel speed of 46 km/h.

What are the undercarriage specifications of the Moxy MT 25 articulated dump truck?

The Moxy MT 25 articulated dump truck is equipped with standard tyres sized 20.5-25.

What is the material handling capacity of the Moxy MT 25 articulated dump truck?

The Moxy MT 25 has a net load capacity of 22.6 tons, a dump capacity of 13.7 cubic meters, and a loading height of 2.75 meters.
