400C John Deere Construction 400C Specifications & Technical Data (2000—2001)

Weight: 28.45t – Standard tyres: 29.5 R25 – Dump capacity: 22m³ – Travel speed: 49km/h – Net load: 36.5t – Transport length: 10.67m

Articulated Dump Trucks John Deere Construction 400C

Technical specs - 400C John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
28.45 t
Standard tyres
29.5 R25
Dump capacity
22 m³
Travel speed
49 km/h
Net load
36.5 t
Transport length
10.67 m
Transport width
3.38 m
Transport height
3.68 m
Turning radius outside
9.21 m
Loading height
2.2 m
Model series
C
Engine manuf.
DaimlerChrysler
Engine type
OM442LA
Engine power
306 kW
Displacement
14.6 l
Max. torque
1750 Nm
No. of cylinders
8

More technical details, like: dimension lxwxh, revolutions at max torque, cylinder bore x stroke, emission level are available in the full technical specs.

Special equipment

Diesel particulate filter
No
Central lubrication
No
Heated dump body
No
Tailgate
No
Aircondition
No

Download datasheets (PDF)

John Deere Construction 400C FAQ

When was the John Deere Construction 400C manufactured?

The John Deere Construction 400C was manufactured from 2000 to 2001.

How much does the John Deere Construction 400C weigh?

The John Deere Construction 400C weighs 28.45 tons.

What are the transport dimensions of the John Deere Construction 400C articulated dump truck?

The John Deere Construction 400C has a transport length of 10.67 meters, a transport width of 3.38 meters, and a transport height of 3.68 meters.

What is the travel speed of the John Deere Construction 400C articulated dump truck?

The John Deere Construction 400C has a travel speed of 49 km/h.

What is the standard tyre size of the John Deere Construction 400C?

The John Deere Construction 400C is equipped with standard tyres sized 29.5 R25.

What is the turning radius of the John Deere Construction 400C articulated dump truck?

The John Deere Construction 400C has an outside turning radius of 9.21 meters.

What is the material handling capacity of the John Deere Construction 400C articulated dump truck?

The John Deere Construction 400C has a net load capacity of 36.5 tons, a dump capacity of 22 cubic meters, and a loading height of 2.2 meters.

How much is a John Deere Construction 400C Articulated dump truck (2000u20132001) worth?

The residual value of the John Deere Construction 400C depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
