DA45-7 Doosan DA45-7 Specifications & Technical Data (2021—2023)
.jpeg)
.jpeg)
Technical specs - DA45-7 Doosan
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 30.5 t
- Standard tyres
- 23.5 R25
- Dump capacity
- 24.4 m³
- Travel speed
- 55 km/h
- Net load
- 41 t
- Transport length
- 10.5 m
- Transport width
- 3.4 m
- Transport height
- 3.8 m
- Turning radius outside
- 8.4 m
- Loading height
- 3.6 m
- Model series
- DA
- Engine manuf.
- Scania
- Engine type
- DC13
- Engine power
- 368 kW
- Dimension lxwxh
- 1398x965x1119 mm
- Displacement
- 12.7 l
- Revolutions at max torque
- 2100 rpm
- Max. torque
- 2476/1300 Nm
- No. of cylinders
- 6
- Cylinder bore x stroke
- 130x160 mm
- Emission level
- Stage V
Special equipment
- Diesel particulate filter
-
No
- Central lubrication
-
No
- Heated dump body
-
No
- Tailgate
-
No
- Aircondition
-
No
Download datasheets (PDF)
