730C Caterpillar 730C Specifications & Technical Data (2014—2017)

The 730 C articulated dump truck model is manufactured by Caterpillar. Find and download detailed specs and data sheets for this m…

The 730 C articulated dump truck model is manufactured by Caterpillar. Find and download detailed specs and data sheets for this machine here.

This articulated dump truck is built to provide up to 276kW or 370 horse power, delivered from its powerful Caterpillar engine to the 22.5t 730 C machine. This Caterpillar articulated dump truck belongs to the medium sized machine segment in the articulated dump trucks category.

The 730 C is manufactured and distributed with Bin heating, Aircondition and Central lubrication. Diesel particulate filter and Tailgate are not provided on this model as of 2017. There are more detailed specifications and machine descriptions available in the original Caterpillar 730 C specs data sheet. You can download it for free in German on LECTURA Specs.

The production is still going in 2017, where this 730 C is available at a new list price between €506000 and €644000. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

The most commonly viewed Caterpillar models of this type on LECTURA Specs are the 745 C, 735 C and 725 C, and 6 other articulated dump trucks, which currently range from 21.7t up to 33.4t are also available. This 730 C articulated dump truck, which has been in production between 2014 and 2017 ranks in the LECTURA index at #12. Currently, 6 models of the 730 C articulated dump truck exist, at an average sale value of €353000 at 2 years of age. Want more detailed specifications? Download the latest Caterpillar 730 C specs data sheet on LECTURA Specs today!

Articulated Dump Trucks Caterpillar 730C

730C

Years of manufacture: 2014—2017

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 730C Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 24.1 t

Standard tyres: 23.5 R 25

Dump capacity: 17.5 m³

Travel speed: 55 km/h

Net load: 28 t

Transport length: 10.445 m

Transport width: 2.902 m

Transport height: 3.779 m

Turning radius outside: 8.075 m

Loading height: 2.911 m

Engine manuf.: Caterpillar

Engine type: C13

Engine power: 280 kW

Displacement: 12.5 l

Revolutions at max torque: 1800 rpm

Cylinder bore x stroke: 130x157 mm

Emission level: Tier 4 f

More technical details, like: model series, dimension lxwxh, max. torque, no. of cylinders, engine manufacturer, engine model, emission rating, number of cylinders, rated speed, engine output - net, engine output - gross, torque, drive configuration, transmission type, transmission manufacturer, transmission model, final drive, traction control, front differential, second axle differential, third axle differential, centre transfer differential, tyre - size, tyre - type, front suspension - type, front suspension, rear suspension - type, rear suspension, service brake - type, length - overall, height - over cab, height - max, ground clearance, width - over tyres, width - transport, width - operating, wheelbase, length - body, loading height, full dump height, hoist - type, hoist - angle, articulation angle, turning radius - outside, turning radius - inside, fuel tank, heaped capacity, cycle time - raise, unladen axle load - front, unladen axle load - centre, unladen axle load - rear, unladen axle load - centre + rear, laden axle load - front, laden axle load - centre, laden axle load - rear, laden axle load - centre + rear, speed - forward maximum, speed - reverse maximum, net weight, payload, gross weight are available in the full technical specs.

Special equipment

Diesel particulate filter: No
Central lubrication: Yes
Heated dump body: Yes
Tailgate: No
Aircondition: Yes

Download specalog and datasheets (PDF)

Caterpillar 730C FAQ

When was the Caterpillar 730C manufactured?

The Caterpillar 730C was manufactured from 2014 to 2017.

How much does the Caterpillar 730C weigh?

The Caterpillar 730C weighs 24.1 tons.

What are the transport dimensions of the Caterpillar 730C articulated dump truck?

The Caterpillar 730C has a transport length of 10.45 meters, a transport width of 2.9 meters, and a transport height of 3.78 meters.

What is the travel speed of the Caterpillar 730C articulated dump truck?

The Caterpillar 730C has a travel speed of 55 km/h.

What are the standard tyre specifications of the Caterpillar 730C articulated dump truck?

The Caterpillar 730C articulated dump truck is equipped with standard tyres sized 23.5 R 25.

What is the turning radius of the Caterpillar 730C articulated dump truck?

The Caterpillar 730C has an outside turning radius of 8.075 meters.

What is the material handling capacity of the Caterpillar 730C articulated dump truck?

The Caterpillar 730C has a net load capacity of 28 tons, a dump capacity of 17.5 cubic meters, and a loading height of 2.91 meters.

How much is a Caterpillar 730C Articulated dump truck (2014u20132017) worth?

The residual value of the Caterpillar 730C depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
