327 B Case 327 B Specifications & Technical Data (2010—2025)

The 327 B articulated dump truck model is manufactured by case. Find and download detailed specs and data sheets for this machine …

The 327 B articulated dump truck model is manufactured by case. Find and download detailed specs and data sheets for this machine here.

The case 327 B is a 22.24t machine with case engine which powers this model with up to 235kW or 315 horse power. This case articulated dump truck belongs to the medium sized machine segment in the articulated dump trucks category. The 327 B’s size is 2.86m x 10.03m x 3.65m.

Diesel particulate filter, Bin heating and Central lubrication are not provided on this model as of 2016. There are more detailed specifications and machine descriptions available in the original case 327 B specs data sheet. Available in English, Spanish, French, Chinese and German, LECTURA Specs offers a free download of highly detailed specifications and machine descriptions of this model.

At present, other articulated dump trucks, which range from up to are produced by case. Of these, are the most frequently visited on LECTURA Specs. Want more detailed specifications? Download the latest case 327 B specs data sheet on LECTURA Specs today!

327 B

Years of manufacture: 2010—2025

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 327 B Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 22.24 t

Standard tyres: 23.5 R 25

Dump capacity: 10.6 m³

Travel speed: 46.6 km/h

Net load: 23.2 t

Transport length: 10.03 m

Transport width: 2.86 m

Transport height: 3.65 m

Loading height: 2.7 m

Model series: B

Engine manuf.: Case

Engine type: Family IV

Engine power: 235 kW

Displacement: 10.3 l

Revolutions at max torque: 2100 rpm

More technical details, like: turning radius outside, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, engine manufacturer, engine model, emission rating, number of cylinders, rated speed, engine output - net, engine output - gross, torque, drive configuration, transmission type, transmission manufacturer, transmission model, final drive, tyre - size, service brake - type, length - overall, height - max, ground clearance, width - over tyres, width - transport, width - operating, loading height, full dump height, hoist - type, hoist - angle, articulation angle, turning radius - outside, fuel tank, heaped capacity, cycle time - raise, net weight, payload, gross weight are available in the full technical specs.

Special equipment

Diesel particulate filter: No
Central lubrication: No
Heated dump body: No
Tailgate: No
Aircondition: No

Download datasheets (PDF)

Case 327 B FAQ

When was the Case 327 B manufactured?

The Case 327 B was first produced in 2010.

How much does the Case 327 B weigh?

The Case 327 B weighs 22.24 tons.

What are the transport dimensions of the Case 327 B articulated dump truck?

The Case 327 B has a transport length of 10.03 meters, a transport width of 2.86 meters, and a transport height of 3.65 meters.

What is the travel speed of the Case 327 B articulated dump truck?

The Case 327 B articulated dump truck has a travel speed of 46.6 km/h.

What are the undercarriage specifications of the Case 327 B articulated dump truck?

The Case 327 B articulated dump truck is equipped with standard tyres sized 23.5 R 25.

What is the material handling capacity of the Case 327 B articulated dump truck?

The Case 327 B articulated dump truck has a net load capacity of 23.2 tons, a dump capacity of 10.6 cubic meters, and a loading height of 2.7 meters.

How much is a Case 327 B Articulated dump truck (2010u20132025) worth?

The residual value of the Case 327 B depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
