B60E Bell B60E Specifications & Technical Data (2017—2019)

Model rating: 1,00 / 10

The B 60 E articulated dump truck model is manufactured by BELL. Find and download detailed specs and data sheets for this machine…

The B 60 E articulated dump truck model is manufactured by BELL. Find and download detailed specs and data sheets for this machine here.

Equipped with a powerful Mercedes-Benz engine, this B 60 E 42.5t machine can provide 430kW or 576 horse power for the articulated dump truck. The BELL B 60 E can be grouped in the biggest machine segment in the articulated dump trucks category. The B 60 E’s size is 4.444m x 11.114m x 4.209m.

The B 60 E is manufactured and distributed with Aircondition and Central lubrication. It does not include Diesel particulate filter, Bin heating and Tailgate. There are more detailed specifications and machine descriptions available in the original BELL B 60 E specs data sheet. Specification sheet is available for a free download in Russian, English, French and German - providing the machine descriptions and more detailed specs about this particular model.

The production is still going in 2017, where this B 60 E is available at a new list price between €606000 and €771000. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

At present, 6 other articulated dump trucks, which range from 19.7t up to 35.3t are produced by BELL. Of these, B 25 E, B 30 E and also B 45 E are the most frequently visited on LECTURA Specs. Having been in production from 2017 to 2017, the B 60 E articulated dump truck ranks in the LECTURA index at #3. Want more detailed specifications? Download the latest BELL B 60 E specs data sheet on LECTURA Specs today!

B60E

Years of manufacture: 2017—2019

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - B60E Bell

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 42.5 t

Standard tyres: VR: 875/65 R 29 / HR: 24.00 R 35

Dump capacity: 35 m³

Travel speed: 47 km/h

Net load: 55 t

Transport length: 11.114 m

Transport width: 4.487 m

Transport height: 4.209 m

Turning radius outside: 9.524 m

Loading height: 3.824 m

Model series: E

Engine manuf.: Mercedes-Benz

Engine type: OM473 LA

Engine power: 430 kW

Displacement: 15.6 l

Revolutions at max torque: 1300 rpm

Max. torque: 2750 Nm

No. of cylinders: 6

Emission level: 4f

More technical details, like: dimension lxwxh, cylinder bore x stroke, engine manufacturer, engine model, emission rating, number of cylinders, rated speed, engine output - net, engine output - gross, torque, drive configuration, transmission type, transmission manufacturer, transmission model, final drive, traction control, front differential, second axle differential, centre transfer differential, tyre - size, tyre - type, front suspension - type, front suspension, rear suspension - type, rear suspension, service brake - type, length - overall, height - over cab, height - max, ground clearance, width - over tyres, width - transport, width - operating, wheelbase, length - body, loading height, hoist - type, hoist - angle, approach angle, articulation angle, turning radius - outside, turning radius - inside, fuel tank, heaped capacity, cycle time - raise, unladen axle load - front, unladen axle load - rear, unladen axle load - centre + rear, laden axle load - front, laden axle load - rear, laden axle load - centre + rear, front - laden, rear - laden, speed - forward maximum, speed - reverse maximum, net weight, payload, gross weight are available in the full technical specs.

Special equipment

Diesel particulate filter: No
Central lubrication: Yes
Heated dump body: No
Tailgate: No
Aircondition: Yes

Download datasheets (PDF)

Bell B60E FAQ

When was the Bell B60E manufactured?

The Bell B60E was manufactured from 2017 to 2019.

How much does the Bell B60E articulated dump truck weigh?

The Bell B60E articulated dump truck weighs 42.5 tons.

What are the transport dimensions of the Bell B60E articulated dump truck?

The Bell B60E has a transport length of 11.11 meters, a transport width of 4.49 meters, and a transport height of 4.21 meters.

What is the travel speed of the Bell B60E articulated dump truck?

The Bell B60E articulated dump truck has a travel speed of 47 km/h.

What are the undercarriage specifications of the Bell B60E articulated dump truck?

The Bell B60E is equipped with standard tyres sized Front: 875/65 R 29 and Rear: 24.00 R 35.

What is the turning radius of the Bell B60E articulated dump truck?

The Bell B60E has an outside turning radius of 9.524 meters.

What is the material handling capacity of the Bell B60E articulated dump truck?

The Bell B60E has a net load capacity of 55 tons, a dump capacity of 35 cubic meters, and a loading height of 3.82 meters.
