ADT 30 C Astra ADT 30 C Specifications & Technical Data (2010—2015)

The ADT 30 C articulated dump truck model is manufactured by Astra. Find and download detailed specs and data sheets for this mach…

The ADT 30 C articulated dump truck model is manufactured by Astra. Find and download detailed specs and data sheets for this machine here.

Equipped with a powerful Iveco engine, this ADT 30 C 22.57t machine can provide 260kW or 348 horse power for the articulated dump truck. The Astra ADT 30 C can be grouped in the medium sized machine segment in the articulated dump trucks category. The ADT 30 C’s size is 3.121m x 10.031m x 3.651m.

The Astra ADT 30 C has been equipped and sold with Aircondition. It does not include Bin heating, Tailgate and Central lubrication. There are more detailed specifications and machine descriptions available in the original Astra ADT 30 C specs data sheet. Available in English and Italian, LECTURA Specs offers a free download of highly detailed specifications and machine descriptions of this model.

The production stopped in 2015, where this ADT 30 C was available at a new list price between €194000 and €247000. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

At present, other articulated dump trucks, which range from up to are produced by Astra. Of these, are the most frequently visited on LECTURA Specs. Want more detailed specifications? Download the latest Astra ADT 30 C specs data sheet on LECTURA Specs today!

ADT 30 C

Years of manufacture: 2010—2015

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - ADT 30 C Astra

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 22.57 t

Standard tyres: 23.5 R 25

Dump capacity: 17.6 m³

Travel speed: 46.6 km/h

Net load: 28.16 t

Transport length: 10.031 m

Transport width: 3.121 m

Transport height: 3.651 m

Turning radius outside: 8.256 m

Loading height: 2.916 m

Model series: ADT

Engine manuf.: Iveco

Engine type: Cursor 10

Engine power: 260 kW

Displacement: 10.3 l

Revolutions at max torque: 1900 rpm

Emission level: TIII

More technical details, like: dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, engine manufacturer, engine model, number of cylinders, rated speed, engine output - gross, drive configuration, transmission type, transmission manufacturer, final drive, tyre - size, tyre - type, length - overall, height - max, ground clearance, width - over tyres, width - transport, width - operating, length - body, loading height, full dump height, hoist - angle, articulation angle, turning radius - outside, turning radius - inside, fuel tank, heaped capacity, cycle time - raise, net weight, payload, gross weight are available in the full technical specs.

Special equipment

Diesel particulate filter: No
Central lubrication: No
Heated dump body: No
Tailgate: No
Aircondition: Yes

Download datasheets (PDF)

ADT 30 C Astra Specification for Europe (EN, IT)

Astra ADT 30 C FAQ

When was the Astra ADT 30 C manufactured?

The Astra ADT 30 C was manufactured from 2010 to 2015.

How much does the Astra ADT 30 C weigh?

The Astra ADT 30 C weighs 22.57 tons.

What are the transport dimensions of the Astra ADT 30 C articulated dump truck?

The Astra ADT 30 C has a transport length of 10.03 meters, a transport width of 3.12 meters, and a transport height of 3.65 meters.

What is the travel speed of the Astra ADT 30 C articulated dump truck?

The Astra ADT 30 C has a travel speed of 46.6 km/h.

What are the standard tyre specifications of the Astra ADT 30 C?

The Astra ADT 30 C is equipped with standard tyres sized 23.5 R 25.

What is the turning radius of the Astra ADT 30 C articulated dump truck?

The Astra ADT 30 C has an outside turning radius of 8.256 meters.

What is the material handling capacity of the Astra ADT 30 C articulated dump truck?

The Astra ADT 30 C has a net load capacity of 28.16 tons, a dump capacity of 17.6 cubic meters, and a loading height of 2.92 meters.

How much is a Astra ADT 30 C Articulated dump truck (2010u20132015) worth?

The residual value of the Astra ADT 30 C depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
