6090HF485 John Deere Construction 6090HF485 Specifications & Technical Data (2017—2026)

The John Deere Construction 6090HF485 engine, manufactured since 2017, has a displacement of 9 liters and a weight of 901 kilogram…

The John Deere Construction 6090HF485 engine, manufactured since 2017, has a displacement of 9 liters and a weight of 901 kilograms. It is equipped with 6 cylinders, each with a bore of 118.4 mm and a stroke of 136 mm. The engine has a maximum torque of 1543 Nm and operates at a maximum power of 280 kW and a minimum power of 242 kW at 2200 RPM.

Engines John Deere Construction 6090HF485

Technical specs - 6090HF485 John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

No. of cylinders
6
Displacement
9 l
Layout
inline
min. Power
242 kW
max. Power
280 kW
RPM
2200
Max. torque
1543 Nm
Tier Max.
Tier 3
Aspiration
T
Weight
901 kg
Bore
118.4 mm
Stroke
136 mm

More technical details, like: tier min., type of cooling, alternative name, model series are available in the full technical specs.
