C1.1 Caterpillar C1.1 Specifications & Technical Data (2019—2026)

The Caterpillar C1.1 engine, manufactured since 2019, has a displacement of 1.13 liters and weighs 87 kilograms. It is equipped wi…

The Caterpillar C1.1 engine, manufactured since 2019, has a displacement of 1.13 liters and weighs 87 kilograms. It is equipped with 3 cylinders, each with a bore of 77 mm and a stroke of 81 mm. The engine operates at a minimum power of 14.4 kW and a maximum power of 18.9 kW at 3400 RPM, with a maximum torque of 86 Nm.

Engines Caterpillar C1.1

Technical specs - C1.1 Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

No. of cylinders
3
Displacement
1.13 l
Layout
Inline
min. Power
14.4 kW
max. Power
18.9 kW
RPM
3400
Max. torque
86 Nm
Tier Max.
EU V / US T4f
Weight
87 kg
Bore
77 mm
Stroke
81 mm

More technical details, like: tier min., aspiration, type of cooling, alternative name, model series are available in the full technical specs.
