1390e Weidemann 1390e Specifications & Technical Data (2023—2024)

Weight: 2.7t – Standard tyres: 10.0/75 - 15.3 AS ET40 – Wheel base: 1.732m – Travel speed: 15km/h – Steering mode: KL – max. height at the shovel pivot point: 3.02m

1390e

Years of manufacture: 2023—2024

Valuate & Sell
Spare parts
Transport
News

Technical specs - 1390e Weidemann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.7 t

Standard tyres: 10.0/75 - 15.3 AS ET40

Wheel base: 1.732 m

Travel speed: 15 km/h

Steering mode: KL

max. height at the shovel pivot point: 3.02 m

Overcharging height: 2.7 m

Max. discharge height: 2.14 m

Transport length: 3.635 m

Transport width: 1.124 m

Transport height: 2.34 m

Engine manuf.: k.A.

Engine type: Elektro

More technical details, like: operating weight, tipping load, turning radius outside, turning radius inside, model series, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Special equipment

Cabin: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Weidemann 1390e FAQ

When was the Weidemann 1390e manufactured?

The Weidemann 1390e was manufactured from 2023 to 2024.

What is the weight of the Weidemann 1390e yard loader?

The Weidemann 1390e yard loader has a weight of 2.7 tonnes.

What are the transport dimensions of the Weidemann 1390e yard loader?

The Weidemann 1390e has a transport length of 3.635 meters, a transport width of 1.124 meters, and a transport height of 2.34 meters.

What is the travel speed of the Weidemann 1390e yard loader?

The Weidemann 1390e has a travel speed of 15 km/h.

What is the maneuverability specification of the Weidemann 1390e?

The Weidemann 1390e features articulated-frame steering for maneuverability.

What are the standard tyre specifications for the Weidemann 1390e?

The Weidemann 1390e is equipped with standard tyres sized 10.0/75 - 15.3 AS ET40.

What is the wheel base of the Weidemann 1390e yard loader?

The Weidemann 1390e has a wheel base of 1.732 meters.

What are the working height and reach specifications of the Weidemann 1390e yard loader?

The Weidemann 1390e has an overcharging height of 2.7 meters, a maximum discharge height of 2.14 meters, and a maximum height at the shovel pivot point of 3.02 meters.
