1390 Weidemann 1390 Specifications & Technical Data (2020—2026)

Weight: 2.7t – Standard tyres: 10.0/75-15.3 AS ET 80 – Tipping load: 2071kg – Wheel base: 1.732m – Travel speed: 20km/h – Steering mode: KL

1390

Years of manufacture: 2020—2026

Data sheet
Valuate & Sell
Spare parts
Transport
News

Technical specs - 1390 Weidemann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.7 t

Standard tyres: 10.0/75-15.3 AS ET 80

Tipping load: 2071 kg

Wheel base: 1.732 m

Travel speed: 20 km/h

Steering mode: KL

max. height at the shovel pivot point: 3 m

Overcharging height: 2.68 m

Max. discharge height: 2.13 m

Turning radius outside: 3.04 m

Turning radius inside: 1.61 m

Transport length: 4 m

Transport width: 1.04 m

Transport height: 2.34 m

Engine manuf.: Yanmar

Engine type: 3TNV86CHT

Engine power: 33.3 kW

Displacement: 1.568 l

Revolutions at max torque: 2600 rpm

No. of cylinders: 3

Emission level: V

More technical details, like: operating weight, model series, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Special equipment

Cabin: Yes
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: Yes

Download datasheets (PDF)

Weidemann 1390 FAQ

When was the Weidemann 1390 first produced?

The Weidemann 1390 was first produced in 2020.

What is the weight of the Weidemann 1390 yard loader?

The Weidemann 1390 yard loader has a weight of 2.7 tonnes.

What are the transport dimensions of the Weidemann 1390 yard loader?

The Weidemann 1390 has a transport length of 4 meters, a transport width of 1.04 meters, and a transport height of 2.34 meters.

What is the travel speed of the Weidemann 1390?

The Weidemann 1390 has a travel speed of 20 km/h.

What are the maneuverability specifications of the Weidemann 1390 yard loader?

The Weidemann 1390 yard loader features articulated-frame steering with an outside turning radius of 3.04 meters and an inside turning radius of 1.61 meters.

What are the standard tyre specifications for the Weidemann 1390?

The Weidemann 1390 is equipped with standard tyres sized 10.0/75-15.3 AS ET 80.

What is the chassis specification of the Weidemann 1390?

The Weidemann 1390 has a wheel base of 1.732 meters.

What is the mass capacity of the Weidemann 1390?

The Weidemann 1390 has a tipping load capacity of 2071 kilograms.

What are the working height and reach specifications of the Weidemann 1390 yard loader?

The Weidemann 1390 has an overcharging height of 2.68 meters, a maximum discharge height of 2.13 meters, and a maximum height at the shovel pivot point of 3 meters.

How much is a Weidemann 1390 Yard loader (2020u20132025) worth?

The residual value of the Weidemann 1390 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
