3348 L Thaler 3348 L Specifications & Technical Data (2016—2020)

Weight: 2.31t – operating weight: 2.51t – Standard tyres: 10.0/75-15.3 AS – Tipping load: 1900kg – Wheel base: 1.95m – Travel speed: 20km/h

Technical specs - 3348 L Thaler

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.31 t
operating weight
2.51 t
Standard tyres
10.0/75-15.3 AS
Tipping load
1900 kg
Wheel base
1.95 m
Travel speed
20 km/h
Steering mode
KL
max. height at the shovel pivot point
2.765 m
Max. discharge height
1.99 m
Turning radius outside
2.385 m
Turning radius inside
1.21 m
Transport length
3.34 m
Transport width
1.16 m
Transport height
2.26 m
Engine manuf.
Yanmar
Engine type
k.A.
Engine power
35.4 kW
Displacement
2.22 l
Revolutions at max torque
3000 rpm
No. of cylinders
4
Emission level
IIIA

More technical details, like: overcharging height, model series, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Special equipment

Cabin
No
telescopic
No
Aircondition
No
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

Thaler 3348 L FAQ

When was the Thaler 3348 L manufactured?

The Thaler 3348 L was manufactured from 2016 to 2020.

What are the weight specifications for the Thaler 3348 L?

The Thaler 3348 L has a standard weight of 2.31 tonnes and an operating weight of 2.51 tonnes.

What are the transport dimensions of the Thaler 3348 L?

The Thaler 3348 L has a transport length of 3.34 meters, a transport width of 1.16 meters, and a transport height of 2.26 meters.

What is the travel speed of the Thaler 3348 L?

The Thaler 3348 L has a travel speed of 20 km/h.

What are the maneuverability specifications of the Thaler 3348 L yard loader?

The Thaler 3348 L features articulated-frame steering with an outside turning radius of 2.385 meters and an inside turning radius of 1.21 meters.

What are the standard tyre specifications for the Thaler 3348 L?

The Thaler 3348 L is equipped with standard tyres sized 10.0/75-15.3 AS.

What is the wheel base of the Thaler 3348 L yard loader?

The Thaler 3348 L has a wheel base of 1.95 meters.

What is the mass capacity of the Thaler 3348 L?

The Thaler 3348 L has a tipping load of 1900 kilograms.

What are the working height specifications of the Thaler 3348 L yard loader?

The Thaler 3348 L has a maximum discharge height of 1.99 meters and a maximum height at the shovel pivot point of 2.77 meters.
