Technical specs - 3248 T-5A Thaler

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 3.1 t

operating weight: 3.3 t

Standard tyres: 400/50-15 AS

Tipping load: 2080 kg

Wheel base: 2.05 m

Travel speed: 20 km/h

Steering mode: KL/A

max. height at the shovel pivot point: 4.056 m

Overcharging height: 3.897 m

Max. discharge height: 3.27 m

Turning radius outside: 2.51 m

Turning radius inside: 0.85 m

Transport length: 4.21 m

Transport width: 1.66 m

Transport height: 2.26 m

Engine manuf.: Yanmar

Engine type: k.A.

Engine power: 35.4 kW

Displacement: 2.22 l

Revolutions at max torque: 3000 rpm

No. of cylinders: 4

Emission level: IIIA

More technical details, like: model series, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Special equipment

Cabin: No
telescopic: Yes
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Thaler 3248 T-5A FAQ

When was the Thaler 3248 T-5A manufactured?

The Thaler 3248 T-5A was manufactured from 2019 to 2020.

What are the weight specifications for the Thaler 3248 T-5A?

The Thaler 3248 T-5A has a standard weight of 3.1 tonnes and an operating weight of 3.3 tonnes.

What are the transport dimensions of the Thaler 3248 T-5A?

The Thaler 3248 T-5A has a transport length of 4.21 meters, a transport width of 1.66 meters, and a transport height of 2.26 meters.

What is the travel speed of the Thaler 3248 T-5A?

The Thaler 3248 T-5A has a travel speed of 20 km/h.

What are the maneuverability specifications of the Thaler 3248 T-5A?

The Thaler 3248 T-5A features all-wheel, articulated-frame steering with an outside turning radius of 2.51 meters and an inside turning radius of 0.85 meters.

What are the tyre specifications of the Thaler 3248 T-5A?

The Thaler 3248 T-5A is equipped with standard tyres sized 400/50-15 AS.

What is the wheelbase of the Thaler 3248 T-5A?

The Thaler 3248 T-5A has a wheel base of 2.05 meters.

What is the mass capacity of the Thaler 3248 T-5A?

The Thaler 3248 T-5A has a tipping load of 2080 kilograms.

What are the working height and reach specifications of the Thaler 3248 T-5A?

The Thaler 3248 T-5A has an overcharging height of 3.9 meters, a maximum discharge height of 3.27 meters, and a maximum height at the shovel pivot point of 4.06 meters.
