2630 SLT Schäffer 2630 SLT Specifications & Technical Data (2021—2026)

Weight: 2.445t – Standard tyres: 10.0/75-15.3 AS – Tipping load: 1321kg – Wheel base: 1.65m – Travel speed: 20km/h – Steering mode: KL

2630 SLT

Years of manufacture: 2021—2026

Data sheet
Valuate & Sell
Spare parts
Transport
News

Technical specs - 2630 SLT Schäffer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.445 t

Standard tyres: 10.0/75-15.3 AS

Tipping load: 1321 kg

Wheel base: 1.65 m

Travel speed: 20 km/h

Steering mode: KL

max. height at the shovel pivot point: 2.88 m

Overcharging height: 2.68 m

Max. discharge height: 2.045 m

Turning radius outside: 2.37 m

Turning radius inside: 1.35 m

Transport length: 3.23 m

Transport width: 1.3 m

Transport height: 1.98 m

Engine manuf.: Kubota

Engine type: D1703-M-DI

Engine power: 18.5 kW

Displacement: 1.647 l

Revolutions at max torque: 2400 rpm

No. of cylinders: 3

Emission level: V

More technical details, like: operating weight, model series, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Special equipment

Cabin: Yes
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Schäffer 2630 SLT FAQ

When did production of the Schu00e4ffer 2630 SLT start?

The Schu00e4ffer 2630 SLT was first produced in 2021.

What is the weight of the Schu00e4ffer 2630 SLT yard loader?

The Schu00e4ffer 2630 SLT yard loader weighs 2.45 tonnes.

What are the physical dimensions of the Schu00e4ffer 2630 SLT yard loader?

The Schu00e4ffer 2630 SLT has a transport length of 3.23 meters, a transport width of 1.3 meters, and a transport height of 1.98 meters.

What is the travel speed of the Schu00e4ffer 2630 SLT?

The Schu00e4ffer 2630 SLT has a travel speed of 20 km/h.

What are the maneuverability specifications of the Schu00e4ffer 2630 SLT yard loader?

The Schu00e4ffer 2630 SLT features articulated-frame steering with an outside turning radius of 2.37 meters and an inside turning radius of 1.35 meters.

What are the standard tyre specifications for the Schu00e4ffer 2630 SLT?

The Schu00e4ffer 2630 SLT is equipped with standard tyres sized 10.0/75-15.3 AS.

What is the wheel base of the Schu00e4ffer 2630 SLT yard loader?

The Schu00e4ffer 2630 SLT has a wheel base of 1.65 meters.

What is the tipping load capacity of the Schu00e4ffer 2630 SLT?

The Schu00e4ffer 2630 SLT has a tipping load capacity of 1321 kilograms.

What is the maximum discharge height of the Schu00e4ffer 2630 SLT?

The Schu00e4ffer 2630 SLT has a maximum discharge height of 2.05 meters.
