Agri Pivot T60 Dieci Agri Pivot T60 Specifications & Technical Data (2013—2016)

Dieci is the manufacturer of the telehandler model Agri Pivot T 60. Find and download detailed specs and data sheets for this mach…

Dieci is the manufacturer of the telehandler model Agri Pivot T 60. Find and download detailed specs and data sheets for this machine here.

Equipped with a powerful Yanmar engine, this Agri Pivot T 60 6.02t machine can provide 55kW or 73 horse power for the telehandler. The Dieci Agri Pivot T 60 can be grouped in the smallest machine segment in the telehandlers category. The Agri Pivot T 60’s size is 1.88m x 5.4m x 2.49m. 405/70-20 is the size of standard tyres equipped on this Dieci Agri Pivot T 60 telehandler. Operators can travel by 40km/h with this telehandler. The model's features include a max. Horizontal reach of 3.4m 2.25t is its maximum nominal load capacity with a 500mm center of gravity. This telehandler from Dieci is able to work with 2.25t capacity at up to 4.7m height. The capacity of this model at full forward reach is 1.3t.

Side displacement, StVZO Equipment and Diesel particulate filter are not provided on this model as of 2018. Take the original Dieci Agri Pivot T 60 datasheet for even more detailed specifications and machine details. You can download it for free in French, German, Italian, English and Spanish on LECTURA Specs.

For more detailed information about pricing and current residual values, check out the LECTURA Valuation system. This machine is still being manufactured by Dieci and is offered with a list price between €91,000 and €116,000.

Comparisons of the Agri Pivot T 60 Dieci with other telehandler models reveal that, based on specifications and pricing, the model is similar to the Merlo Multifarmer 27.8. The most commonly viewed Dieci models of this type on LECTURA Specs are the Agri Plus 40.7 PS EVO2, Icarus 40.17-85 and Agri Star 37.7, and 78 other telehandlers, which currently range from 1.8t up to 21t are also available. Ranked in the LECTURA index at #111, this Agri Pivot T 60 telehandler has models that date from 2013 to 2018. Want more detailed specifications? Download the latest Dieci Agri Pivot T 60 specs data sheet on LECTURA Specs today!

Agri Pivot T60

Years of manufacture: 2013—2016

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - Agri Pivot T60 Dieci

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 6.02 t

Standard tyres: 405/70-20

Travel speed: 40 km/h

Transport length: 5.4 m

Transport width: 1.88 m

Transport height: 2.49 m

Model series: Agri Pivot

Engine manuf.: Yanmar

Engine type: V3307CR-TE4B

Engine power: 54.6 kW

Displacement: 3.331 l

Revolutions at max torque: 1500 rpm

Max. torque: 265 Nm

No. of cylinders: 4

Emission level: IIIB/Tier 4i

More technical details, like: operating weight, tipping load, wheel base, steering mode, max. height at the shovel pivot point, overcharging height, max. discharge height, turning radius outside, turning radius inside, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Special equipment

Cabin: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Dieci Agri Pivot T60 FAQ

When was the Dieci Agri Pivot T60 manufactured?

The Dieci Agri Pivot T60, part of the Agri Pivot series, was manufactured from 2013 to 2016.

What is the weight of the Dieci Agri Pivot T60?

The Dieci Agri Pivot T60 has a weight of 6.02 tonnes.

What are the transport dimensions of the Dieci Agri Pivot T60 yard loader?

The Dieci Agri Pivot T60 has a transport length of 5.4 meters, a transport width of 1.88 meters, and a transport height of 2.49 meters.

What is the travel speed of the Dieci Agri Pivot T60?

The Dieci Agri Pivot T60 has a travel speed of 40 km/h.

What are the tyre specifications of the Dieci Agri Pivot T60?

The Dieci Agri Pivot T60 is equipped with standard tyres sized 405/70-20.

How much is a Dieci Agri Pivot T60 Yard loader (2013u20132016) worth?

The residual value of the Dieci Agri Pivot T60 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
