Torion 1914 Claas Torion 1914 Specifications & Technical Data (2017—2019)

Weight: 19.5t – Standard tyres: 23.5 R25 L3 – Tipping load: 12400kg – Wheel base: 3.395m – Travel speed: 40km/h – Steering mode: KL

Torion 1914

Years of manufacture: 2017—2019

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - Torion 1914 Claas

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 19.5 t

Standard tyres: 23.5 R25 L3

Tipping load: 12400 kg

Wheel base: 3.395 m

Travel speed: 40 km/h

Steering mode: KL

Max. discharge height: 4.075 m

Turning radius outside: 6.65 m

Transport length: 8.605 m

Transport height: 3.37 m

Engine manuf.: Liebherr

Engine type: D 944 A7

Engine power: 168 kW

Displacement: 7.96 l

Max. torque: 1433/1100 Nm

No. of cylinders: 4

Emission level: IV

More technical details, like: operating weight, max. height at the shovel pivot point, overcharging height, turning radius inside, transport width, model series, dimension lxwxh, revolutions at max torque, cylinder bore x stroke are available in the full technical specs.

Special equipment

Cabin: Yes
telescopic: No
Aircondition: Yes
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Claas Torion 1914 FAQ

When was the Claas Torion 1914 manufactured?

The Claas Torion 1914 was manufactured from 2017 to 2019.

What is the weight of the Claas Torion 1914?

The Claas Torion 1914 has a weight of 19.5 tonnes.

What are the physical dimensions of the Claas Torion 1914 yard loader?

The Claas Torion 1914 has a transport length of 8.61 meters and a transport height of 3.37 meters.

What is the travel speed of the Claas Torion 1914?

The Claas Torion 1914 has a travel speed of 40 km/h.

What are the maneuverability specifications of the Claas Torion 1914?

The Claas Torion 1914 features articulated-frame steering and has an outside turning radius of 6.65 meters.

What are the tyre specifications of the Claas Torion 1914 yard loader?

The Claas Torion 1914 is equipped with standard tyres sized 23.5 R25 L3.

What is the wheelbase of the Claas Torion 1914?

The Claas Torion 1914 has a wheelbase of 3.395 meters.

What is the mass capacity of the Claas Torion 1914?

The Claas Torion 1914 has a tipping load of 12,400 kilograms.

What is the maximum discharge height of the Claas Torion 1914?

The Claas Torion 1914 has a maximum discharge height of 4.08 meters.

How much is a Claas Torion 1914 Yard loader (2017u20132019) worth?

The residual value of the Claas Torion 1914 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Buy & Rent

Compare Claas Torion 1914 with similar Yard loader

Claas Torion 1914

Weight:: 19.5 t

Standard tyres:: 23.5 R25 L3

Tipping load:: 12400 kg

Wheel base:: 3.395 m

Claas Torion 1812

Weight:: 18.7 t

Standard tyres:: 23.5 R25 L3

Tipping load:: 12800 kg

Wheel base:: 3.385 m
