Torion 1913 Claas Torion 1913 Specifications & Technical Data (2022—2026)

Weight: 18.55t – Standard tyres: 23.5 R25 – Tipping load: 11400kg – Travel speed: 40km/h – Steering mode: KL – max. height at the shovel pivot point: 4.15m

Torion 1913

Years of manufacture: 2022—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - Torion 1913 Claas

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 18.55 t

Standard tyres: 23.5 R25

Tipping load: 11400 kg

Travel speed: 40 km/h

Steering mode: KL

max. height at the shovel pivot point: 4.15 m

Overcharging height: 3.7 m

Max. discharge height: 4.075 m

Turning radius outside: 6.65 m

Turning radius inside: 3.54 m

Transport length: 8.605 m

Transport width: 2.65 m

Transport height: 3.37 m

Model series: Torion

Engine manuf.: Liebherr

Engine type: D 943 A7

Engine power: 163 kW

Displacement: 7 l

Revolutions at max torque: 1800 rpm

Max. torque: 1248/1100 Nm

No. of cylinders: 4

Cylinder bore x stroke: 122x150 mm

Emission level: V

More technical details, like: operating weight, wheel base, dimension lxwxh are available in the full technical specs.

Special equipment

Cabin: Yes
telescopic: No
Aircondition: Yes
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Claas Torion 1913 FAQ

When did production of the Claas Torion 1913 start?

The Claas Torion 1913 was first produced in 2022.

What is the weight of the Claas Torion 1913?

The Claas Torion 1913 has a weight of 18.55 tonnes.

What are the transport dimensions of the Claas Torion 1913?

The Claas Torion 1913 has a transport length of 8.61 meters, a transport width of 2.65 meters, and a transport height of 3.37 meters.

What is the travel speed of the Claas Torion 1913?

The Claas Torion 1913 has a travel speed of 40 km/h.

What are the maneuverability specifications of the Claas Torion 1913?

The Claas Torion 1913 features articulated-frame steering with an outside turning radius of 6.65 meters and an inside turning radius of 3.54 meters.

What are the tyre specifications of the Claas Torion 1913?

The Claas Torion 1913 is equipped with standard tyres sized 23.5 R25.

What is the tipping load capacity of the Claas Torion 1913?

The Claas Torion 1913 has a tipping load capacity of 11,400 kilograms.

What are the working height and reach specifications of the Claas Torion 1913?

The Claas Torion 1913 has an overcharging height of 3.7 meters, a maximum discharge height of 4.08 meters, and a maximum height at the shovel pivot point of 4.15 meters.

How much is a Claas Torion 1913 Yard loader (2022u20132025) worth?

The residual value of the Claas Torion 1913 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Buy & Rent

Compare Claas Torion 1913 with similar Yard loader

Claas Torion 1913

Weight:: 18.55 t

Standard tyres:: 23.5 R25

Tipping load:: 11400 kg

Travel speed:: 40 km/h

Claas Torion 1812

Weight:: 18.7 t

Standard tyres:: 23.5 R25 L3

Tipping load:: 12800 kg

Travel speed:: 49 km/h
