Rogator 355 Fendt Rogator 355 Specifications & Technical Data (2019—2022)

The Rogator for all seasons.

In the plant protection sector, there's one name that gives you precise boom control, easy handling and optimal, reliable application: Rogator. Our many years of experience and a number of key technologies have all gone into our innovative Rogator 300 to create the perfect solution.

Rogator 300 Features

We have reviewed countless customer surveys, performed extensive practical tests, and have combined everything in the Rogator 300 that our Fendt customers expect: perfect boom position, user-friendliness, efficient use of resources, and the best equipment. A plant protection implement designed simply to focus on the customer’s needs.

Very efficient operation

All machine functions can be operated from the Varioterminal 10.4" in combination with a Fendt tractor, with an additional terminal as an option. Our multifunction joystick offers you exceptional comfort and convenience, and is specially optimised for use with our plant protection technology. This allows you to conveniently control all sprayer functions via easily accessible buttons. The optional cameras give you perfect all-round visibility, right around the machine. The customised display gives all the key information you need at a glance.

Fully ISOBUS-capable

The Rogator 300 is fully ISOBUS-compatible. The ISOBUS functionality ensures that tractor and plant protection sprayer can be easily combined.

A perfect concentration from start to finish

The permanent circulation through the 1" spray line feeds the solution straight to the diffuser as soon as the rotor pump is switched on, even if the diffusers are closed. Apply the right quantity and concentration of liquid across the entire working width from the very first metre. To clean the diffusers, switch the intake end of the pump over to the clean water tank, and briefly switch on the diffusers. This is how you reliably and effectively prevent deposits in the diffuser pipe and diffusers. Easy, quick, reliable – from the convenience of the operator’s seat.

Operator convenience

All filling fittings are clearly arranged on the left-hand side of the machine. The large and easy to open panels of the Rogator 300 consist of the same HDPE material as the spray tank. Extremely smooth, glass-like surfaces effectively prevent sticking and are easy to clean. Cleverly-designed and sealed stowage compartments allow personal protective equipment and funnels to be carried safely. The hydraulic agitator power can be adjusted from the terminal. Foaming residues are prevented by the agitator control which is linked to the fill level.

Operation

All valve functions required for filling and stirring can be operated from the OptiFlow control centre on the induction hopper, as well as from the cab. The standard automatic filling system stops exactly at the number of litres set by the operator – even if there are two figures, e.g. water and pesticides. This system always guarantees an optimal spray liquid mixture in the tank at all times and reliably prevents overfilling.

Section engagement for increased efficiency

The automatic section engagement facility is absolutely essential for those who need 100% efficiency. Valuable liquids are not used twice on the same area, and there are no overlapping or gaps. This applies to large areas as well as to smaller, winding run-outs. The ISOBUS standard function TC-SC (TaskController SectionControl) automatically engages sections depending on the GPS position and the required degree of overlapping. SectionControl can also produce higher yields while saving 15% of the spray liquid costs.

Headland management

Headland management activates a range of functions at the touch of a single button. Turn on/off the application process, OptiSonic boom control, boom flushing, rear axle control, or switch the cruise control and VarioGuide guidance system. All this helps take the stress out of your working day. If field boundaries are stored, there's no risk that application of liquid will start if the boom moves beyond the field boundary. Even if the run-in lines are unclear or if you work at night, you’ll only treat your target area.

Sturdy frame

The undenable backbone of the machine, developed from the self-propelled frame, forms the basis for precise application and therefore effective use of your spray liquid. The boom is guided in front of the rear axle, so that the chassis only transfers minimal movements to the boom. The Rogator 300 always works with the utmost precision.

Perfect trailing with OptiSteer steering axle

The 30° steering angle with OptiSteer steering axle allows for a turning radius of just 3.8 m, which is always perfectly coordinated with the tractor’s rear axle. The Fendt Rogator is therefore highly agile, and even protects your crop when turning. The high-performance hydraulics or air pressure brake ensures safety on the roads, regardless of whether the tank is full or empty. Wheel tracks from 1.5 m to 2.25 m are available on request.

Flexible drawbar

The universal drawbar allows the Rogator 300 to be used with clevis-type coupling and hitch-type couplings, with all drawbar eyes available on the market, or with ball couplings. You can switch between clevis-type coupling and hitch-type coupling at any time. The tractor’s load-sensing hydraulics efficiently power the Rogator 300, with a PTO drive also available on request.

High-performance pump

A rotary pump with optionally self-priming unit and 785 l/min pump capacity, driven by the load-sensing hydraulics or PTO, supplies all liquid-distributing parts of the system. The flow rate of the rotary pump prevents pulsation in the lines and ensures maximum application accuracy. There are no additional hoses or relief valves which are difficult to clean on membrane pumps. Application quantities are controlled via the pump speed – quickly and efficiently – and the pump only carries the required quantity of liquid for spraying, plus the specified quantity for the agitator. This helps the Rogator 300 to respond accurately to changing application quantities and different speeds.

Reliability with no strings attached

Our low-maintenance pump guarantees excellent reliability and low operating costs. Combined with the 3” fitting, you have everything you need to fill the tank quickly.
