Multi-Master 122 ET 3 Kuhn Multi-Master 122 ET 3 Specifications & Technical Data (2007—2013)

max. working width: 1.35m – Weight: 0.906t – No. of furrows: 3 – Body spacing: 1020mm – Required power: 48kW – Attachment: ZD

Ploughs Kuhn Multi-Master 122 ET 3

Technical specs - Multi-Master 122 ET 3 Kuhn

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

max. working width
1.35 m
Weight
0.906 t
No. of furrows
3
Body spacing
1020 mm
Required power
48 kW
Attachment
ZD
Frame height
800 mm
Cutting width
450 mm

More technical details, like: transport width, leg thickness, construction type, stone protection are available in the full technical specs.

Special equipment

Tyres for transport
No
Packer arm
No

Kuhn Multi-Master 122 ET 3 FAQ

When was the Kuhn Multi-Master 122 ET 3 manufactured?

The Kuhn Multi-Master 122 ET 3 was manufactured from 2007 to 2013.

What is the weight of the Kuhn Multi-Master 122 ET 3?

The Kuhn Multi-Master 122 ET 3 weighs 0.91 tonnes.

What is the required power for the Kuhn Multi-Master 122 ET 3?

The Kuhn Multi-Master 122 ET 3 requires a power of 48 kW.

What are the primary working dimensions of the Kuhn Multi-Master 122 ET 3?

The Kuhn Multi-Master 122 ET 3 has a maximum working width of 1.35 meters and a cutting width of 450 millimeters.

What type of implement hitching does the Kuhn Multi-Master 122 ET 3 use?

The Kuhn Multi-Master 122 ET 3 uses a drawbar attachment for implement hitching.

What are the key tillage and cultivation components of the Kuhn Multi-Master 122 ET 3?

The Kuhn Multi-Master 122 ET 3 has 3 furrows, a body spacing of 1020 mm, and a frame height of 800 mm.

How much is a Kuhn Multi-Master 122 ET 3 Plough (2007u20132013) worth?

The residual value of the Kuhn Multi-Master 122 ET 3 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
