Arion 630 Hexashift Claas Arion 630 Hexashift Specifications & Technical Data (2019—2026)

The Claas Arion 630 Hexashift is a 4-wheel drive tractor manufactured by Claas since 2019. It has a weight of 6.58 tons and is pow…

The Claas Arion 630 Hexashift is a 4-wheel drive tractor manufactured by Claas since 2019. It has a weight of 6.58 tons and is powered by an engine with a capacity of 121 kW. The tractor has a transport length of 5.16 meters and can travel at a speed of 40 km/h. It has a transport height of 3.01 meters and is equipped with special equipment such as air conditioning and a cabin.

Arion 630 Hexashift

Years of manufacture: 2019—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - Arion 630 Hexashift Claas

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power: 121 kW

Model series: Arion

Back tyres: 650/65 R42

Front tyres: 540/65 R30

Transport length: 5.16 m

Transport height: 3.01 m

Travel speed: 40 km/h

Transmission: 24/24

Transmission type: LS

Weight: 6.58 t

Control unit: -/3 ew/dw

Steering: h

three point category: 3

Engine manuf.: John Deere

Engine type: D.P.S. PSS

Displacement: 6.788 l

Revolutions at max torque: 1800-2100 rpm

Max. torque: 703/1500 Nm

No. of cylinders: 6

Emission level: V

is a 0 for the size specification so that means, that no information is available.

Special equipment

Cabin: Yes
Front hydraulics: No
Front PTO: No
Air brakes: No
ISO Bus: No
Aircondition: Yes

Download datasheets (PDF)

Claas Arion 630 Hexashift FAQ

When did production of the Claas Arion 630 Hexashift start?

The Claas Arion 630 Hexashift, part of the Arion series, has been in production since 2019.

What is the weight of the Claas Arion 630 Hexashift?

The Claas Arion 630 Hexashift has a weight of 6.58 tonnes.

What are the physical dimensions of the Claas Arion 630 Hexashift?

The Claas Arion 630 Hexashift has a transport length of 5.16 meters and a transport height of 3.01 meters.

What is the engine power of the Claas Arion 630 Hexashift?

The Claas Arion 630 Hexashift has an engine power of 121 kW.

What is the travel speed of the Claas Arion 630 Hexashift?

The Claas Arion 630 Hexashift has a travel speed of 40 km/h.

What are the drivetrain and transmission specifications of the Claas Arion 630 Hexashift?

The Claas Arion 630 Hexashift features a Powershift transmission with 24 forward and 24 reverse speeds.

What type of steering does the Claas Arion 630 Hexashift have?

The Claas Arion 630 Hexashift is equipped with hydraulic steering.

What are the wheel and tyre specifications of the Claas Arion 630 Hexashift?

The Claas Arion 630 Hexashift has front tyres sized 540/65 R30 and back tyres sized 650/65 R42.

What is the three-point hitch category of the Claas Arion 630 Hexashift?

The Claas Arion 630 Hexashift has a category 3 three-point hitch.

How much is a Claas Arion 630 Hexashift 4WD Tractor (2019u20132025) worth?

The residual value of the Claas Arion 630 Hexashift depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
