5100 Arbos 5100 Specifications & Technical Data (2015—2026)

The Arbos 5100 is a 4-wheel drive tractor manufactured by Arbos since 2015. It has a weight of 4.2 tons and is powered by an engin…

The Arbos 5100 is a 4-wheel drive tractor manufactured by Arbos since 2015. It has a weight of 4.2 tons and is powered by an engine with a capacity of 81 kW. The tractor has a transport length of 4.249 meters and can travel at a speed of 50 km/h. It has a transport width of 2.348 meters and a transport height of 2.756 meters. The tractor is equipped with 4 control units and comes with special equipment such as air conditioning and a cabin.

4WD Tractors Arbos 5100
4WD Tractors Arbos 5100
4WD Tractors Arbos 5100
4WD Tractors Arbos 5100
4WD Tractors Arbos 5100
4WD Tractors Arbos 5100
4WD Tractors Arbos 5100
4WD Tractors Arbos 5100
4WD Tractors Arbos 5100
4WD Tractors Arbos 5100

Technical specs - 5100 Arbos

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Engine power
81 kW
Model series
5000
Back tyres
540/65 R34
Front tyres
440/65 R24
Transport length
4.249 m
Transport width
2.348 m
Transport height
2.756 m
Travel speed
50 km/h
Transmission
5
Transmission type
LS
Weight
4.2 t
Control unit
4 ew/dw
Steering
h
three point category
3
Engine manuf.
Kohler
Engine type
3404 TCR
Displacement
3.4 l
Revolutions at max torque
2200 rpm
Max. torque
470/1400 Nm
No. of cylinders
4
Emission level
Tier IV Final

More technical details, like: dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

is a 0 for the size specification so that means, that no information is available.

Special equipment

Cabin
Yes
Front hydraulics
No
Front PTO
No
Air brakes
No
ISO Bus
No
Aircondition
Yes

Download datasheets (PDF)

Arbos 5100 FAQ

When was the Arbos 5100 manufactured?

The Arbos 5100 was first produced in 2015.

What is the weight of the Arbos 5100 tractor?

The Arbos 5100 tractor has a weight of 4.2 tonnes.

What are the physical dimensions of the Arbos 5100 tractor?

The Arbos 5100 tractor has a transport length of 4.25 meters, a transport width of 2.35 meters, and a transport height of 2.76 meters.

What is the engine power of the Arbos 5100?

The Arbos 5100 has an engine power of 81 kW.

What is the travel speed of the Arbos 5100?

The Arbos 5100 has a travel speed of 50 km/h.

What are the drivetrain and propulsion system specifications of the Arbos 5100?

The Arbos 5100 has a Powershift transmission with 5 speeds.

What type of steering does the Arbos 5100 have for maneuverability?

The Arbos 5100 is equipped with hydraulic steering for maneuverability.

What are the wheel and tyre specifications of the Arbos 5100?

The Arbos 5100 has front tyres sized 440/65 R24 and back tyres sized 540/65 R34.

What is the three-point hitch category of the Arbos 5100?

The Arbos 5100 has a category 3 three-point hitch.
