    Sany SPK 42502 C Specifications & Technical Data (2017-2022)

    Rate this machine now!

    Sany is the manufacturer of the hydraulic loading crane model SPK 42502 C. Find and download detailed specs and data sheets for th... Read more

    Sany is the manufacturer of the hydraulic loading crane model SPK 42502 C. Find and download detailed specs and data sheets for this machine here.

    The SPK 42502 C is categorised in the biggest machine segment in the hydraulic loading crane category. The measurements of this hydraulic loading crane are 2.298m x 2.298m. To be able to lift loads, the SPK 42502 C crane is equipped with a 12.1m-long boom. The carrying capacity of this Hydraulic Loading Crane is 14.34t. Sany SPK 42502 C has 414.82kNm in load torque.

    Adjustable pivoting, Electronic load torque limitation and Remote control are not provided on this model as of 2018. Find detailed specifications and machine details in the original Sany SPK 42502 C datasheet.

    To this day, this machine is still being manufactured.

    Sany currently produces 42 other hydraulic loading cranes, which range from 74.5kNm up to 562kNm - the most visited on LECTURA Specs are SPK 18500 A, SPK 15500 Std., SPK 23500 B. Want more detailed specifications? Download the latest Sany SPK 42502 C specs data sheet on LECTURA Specs today!

    Technical specs - SPK 42502 C Sany

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

    • Load Torque 414.82 kNm
    • machine length 2.298 m
    • machine width 2.298 m
    • machine height 2.345 m
    • max. standard boom 12.1 m
    • Carrying capacity 2.7 t
    • at max. reach 12.1 m
    • Weight 3.97 t
    • max. carrying capacity 14.34 t
    • at reach 2.5 m
    • Load of additional Jib ###
    • max. hook height ###
    • Required power ###

    unmounted without accessories LMB = load torque limit Schwb.= pivot range

    Special equipment

    • Hydr. brace support
    • Electronic load torque limitation
    • Endless pivoting
    • High seat
    • Remote control
    • Adjustable pivoting
    • Articulated boom overstraining
