PK 6501 Palfinger PK 6501 Specifications & Technical Data (2008—2016)

Matchless in even the most challenging situations

The PK 7001 EH is designed to perform in the most demanding environments, providing unmatched reliability and strength. Its advanced features ensure that it can handle the toughest tasks with ease, making it an invaluable asset in any challenging situation.

Radio remote control

Radio remote control with digital data transmission (standard on EH models) offers maximum efficiency and comfort. The display integrated in the handset informs the crane operator continuously about the current capacity loading level of the crane.

Paltronic 50

Modern electronics in the increasingly complex crane system offers safety and comfort functions which make the crane operator’s work easier and increases the efficiency of the crane job.

Load-holding valve

They prevent the crane boom from dropping and are fitted as standard on all slewing, lifting, knuckle-boom and extension cylinders. The valves are positioned in such a way that they are protected against damage.

Return oil utilisation

The high speed of the extension system is impressive. It results from return oil utilisation, which is installed as standard, and the generously dimensioned hydraulic lines. This increases efficiency in all types of applications!

ISC (optional)

The integrated stability control (ISC) is a system that monitors the stability of the crane vehicle. The system adjusts the crane’s lifting forces depending on the current stability support situation and the crane boom to ensure the vehicle’s stability over the entire working area.

Package model PK 7001 EH

Package model PK 7001 EH:E-HPLSPaltronic 50Radio remote control with LED displayDanfoss control valve or PVG200075 l oil tank

Maintenance-free extension system

With the maintenance-free extension system PALFINGER sets a clear path in easy servicing. The use of sliding elements made of special plastic in combination with the proven KTL cathodic dip painting means that the extension boom system no longer has to be serviced by the operator. This not only saves time and expense but also protects the environment.

KTL – the cathodic dip painting

The shot-blasted crane parts are covered in zinc phosphate in an immersion process and coated electro-statically. The subsequent two-component top coating of paint provides a surface protection which in the past was usually only found in the automotive industry.

AOS (optional)

The Active Oscillation Suppression system available exclusively from PALFINGER compensates for jolts and sharp stress cycles caused by crane operation. Because oscillations are eradicated the crane can work with precision, much faster and therefore more cost-efficiently.

Control console

All important information about the crane can be seen on the main control stand. A digital indicator counts and displays the operating hours. Ergonomic control levers and the optional lighting package provide increased safety and comfort even in poor visibility conditions.

Lighting package (optional)

The control stand is supplied on request with LED illumination and backlit symbols. LED warning lights are fitted on the outriggers to provide better visibility.
