8520-OK4 HMF 8520-OK4 Specifications & Technical Data (2010—2017)

The HMF 8520-OK4 is a truck-mounted loading crane manufactured by HMF from 2010 to 2017. It has a weight of 7.335 tons and a carry…

The HMF 8520-OK4 is a truck-mounted loading crane manufactured by HMF from 2010 to 2017. It has a weight of 7.335 tons and a carrying capacity of 3.025 tons. The crane has a load torque of 721 kNm and can reach a maximum distance of 19.3 meters. Its standard boom has a maximum length of 12.4 meters. The machine itself has a length of 2.5 meters, a width of 1.43 meters, and a height of 2.495 meters. It is equipped with adjustable pivoting, electronic load torque limitation, endless pivoting, hydraulic brace support, and remote control.

Hydraulic loading cranes HMF 8520-OK4

Technical specs - 8520-OK4 HMF

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Load Torque
721 kNm
machine length
2.5 m
machine width
1.43 m
machine height
2.495 m
max. standard boom
12.4 m
Carrying capacity
3.025 t
at max. reach
19.3 m
Weight
7.335 t

More technical details, like: load of additional jib, max. carrying capacity, at reach, max. hook height, required power, model series are available in the full technical specs.

unmounted without accessories LMB = load torque limit Schwb.= pivot range

Special equipment

Hydr. brace support
Yes
Electronic load torque limitation
Yes
Endless pivoting
Yes
High seat
No
Remote control
Yes
Adjustable pivoting
Yes
Articulated boom overstraining
No
