    HMF 810-K2 Specifications & Technical Data (2017-2019)

    Rate this machine now!

    HMF is the manufacturer of the hydraulic loading crane model 810-K2. Find and download detailed specs and data sheets for this mac... Read more

    HMF is the manufacturer of the hydraulic loading crane model 810-K2. Find and download detailed specs and data sheets for this machine here.

    The HMF 810-K2 can be grouped in the smallest machine segment in the hydraulic loading crane category. The measurements of this hydraulic loading crane are 2.2m x 0.661m. To be able to lift loads, the 810-K2 crane is equipped with a 7.3m-long boom. The load torque of this model is 67kNm.

    It does not include Electronic load torque limitation, Articulated boom overstraining and High seat. Find detailed specifications and machine details in the original HMF 810-K2 datasheet. Specification sheet is available for a free download in Spanish, German, French and English - providing the machine descriptions and more detailed specs about this particular model.

    Manufacturing of this model is still ongoing.

    At present, 429 other hydraulic loading cranes, which range from 5kNm up to 756kNm are produced by HMF. Of these, 6020-K6 , 260-T2 and also 340-K2 are the most frequently visited on LECTURA Specs. Ranked in the LECTURA index at #3428, this 810-K2 hydraulic loading crane has models that date from 2017 to 2018. Want more detailed specifications? Download the latest HMF 810-K2 specs data sheet on LECTURA Specs today!

    Technical specs - 810-K2 HMF

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    • Load Torque 67 kNm
    • machine length 2.2 m
    • machine width 0.661 m
    • machine height 1.91 m
    • max. standard boom 7.3 m
    • Carrying capacity 0.7 t
    • at max. reach 9.1 m
    • Weight 0.76 t
    • Load of additional Jib ###
    • max. carrying capacity ###
    • at reach ###
    • max. hook height ###
    • Required power ###

    unmounted without accessories LMB = load torque limit Schwb.= pivot range

    Special equipment

    • Hydr. brace support
    • Electronic load torque limitation
    • Endless pivoting
    • High seat
    • Remote control
    • Adjustable pivoting
    • Articulated boom overstraining
