    HMF 610-K2 Specifications & Technical Data (2017-2019)

    Rate this machine now!

    HMF is the manufacturer of the hydraulic loading crane model 610-K2. Find and download detailed specs and data sheets for this mac... Read more

    HMF is the manufacturer of the hydraulic loading crane model 610-K2. Find and download detailed specs and data sheets for this machine here.

    This HMF Hydraulic Loading Crane belongs to the smallest machine segment in the hydraulic loading crane category. Dimensions of 610-K2 model are 2.1m length and 0.661m width. To be able to lift loads, the 610-K2 crane is equipped with a 7.1m-long boom. HMF 610-K2 has 53kNm in load torque.

    It has been sold without Hydr. Brace support, Remote control and High seat as of 2018. Find detailed specifications and machine details in the original HMF 610-K2 datasheet. You can download it for free in Spanish, German and English on LECTURA Specs.

    To this day, this machine is still being manufactured.

    The most commonly viewed HMF models of this type on LECTURA Specs are the 260-T2, 6020-K6 and 340-K2 , and 429 other hydraulic loading cranes are currently available, ranging from 5kNm up to 756kNm. This 610-K2 hydraulic loading crane, which was produced between 2017 and 2018 ranks in the LECTURA index at #3424. Want more detailed specifications? Download the latest HMF 610-K2 specs data sheet on LECTURA Specs today!

    Technical specs - 610-K2 HMF

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    • Load Torque 53 kNm
    • machine length 2.1 m
    • machine width 0.661 m
    • machine height 1.84 m
    • max. standard boom 7.1 m
    • Carrying capacity 0.54 t
    • at max. reach 8.9 m
    • Weight 0.73 t
    • Load of additional Jib ###
    • max. carrying capacity ###
    • at reach ###
    • max. hook height ###
    • Required power ###

    unmounted without accessories LMB = load torque limit Schwb.= pivot range

    Special equipment

    • Hydr. brace support
    • Electronic load torque limitation
    • Endless pivoting
    • High seat
    • Remote control
    • Adjustable pivoting
    • Articulated boom overstraining
