    HMF 610-K1 Specifications & Technical Data (2017-2019)

    Rate this machine now!

    HMF is the manufacturer of the hydraulic loading crane model 610-K1. Find and download detailed specs and data sheets for this mac... Read more

    HMF is the manufacturer of the hydraulic loading crane model 610-K1. Find and download detailed specs and data sheets for this machine here.

    The 610-K1 is categorised in the smallest machine segment in the hydraulic loading crane category. The measurements of this hydraulic loading crane are 2.1m x 0.661m. The longest standard boom the HMF 610-K1 can have is 5.2m. The manufacturer's datasheet guarantees 54kNm in load torque.

    It has been sold without Adjustable pivoting, Remote control and High seat as of 2018. More detailed specifications and machine descriptions can be found in the original HMF 610-K1 specs data sheet. Specification sheet is available for a free download in French, Spanish, German and English - providing the machine descriptions and more detailed specs about this particular model.

    The production of the 610-K1 is still going on.

    At present, 429 other hydraulic loading cranes, which range from 5kNm up to 756kNm are produced by HMF. Of these, 6020-K6 , 260-T2 and also 340-K2 are the most frequently visited on LECTURA Specs. This 610-K1 hydraulic loading crane, which was produced between 2017 and 2018 ranks in the LECTURA index at #2035. Want more detailed specifications? Download the latest HMF 610-K1 specs data sheet on LECTURA Specs today!

    Technical specs - 610-K1 HMF

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    • Load Torque 54 kNm
    • machine length 2.1 m
    • machine width 0.661 m
    • machine height 1.84 m
    • max. standard boom 5.2 m
    • Carrying capacity 0.74 t
    • at max. reach 7.1 m
    • Weight 0.655 t
    • Load of additional Jib ###
    • max. carrying capacity ###
    • at reach ###
    • max. hook height ###
    • Required power ###

    unmounted without accessories LMB = load torque limit Schwb.= pivot range

    Special equipment

    • Hydr. brace support
    • Electronic load torque limitation
    • Endless pivoting
    • High seat
    • Remote control
    • Adjustable pivoting
    • Articulated boom overstraining
