6020-OK6 HMF 6020-OK6 Specifications & Technical Data (2010—2017)

The HMF 6020-OK6 is a truck-mounted loading crane manufactured by HMF from 2010 to 2017. It has a weight of 6.225 tons and a carry…

The HMF 6020-OK6 is a truck-mounted loading crane manufactured by HMF from 2010 to 2017. It has a weight of 6.225 tons and a carrying capacity of 2.64 tons. With a load torque of 517 kNm, it can reach a maximum distance of 16.9 meters. The crane also has the capability to handle an additional jib load of 0.4 tons. Its standard boom can extend up to 17 meters. The machine itself has a length of 2.5 meters, a width of 1.46 meters, and a height of 2.425 meters. At its maximum reach, the machine measures 29.9 meters. It is equipped with special features such as adjustable pivoting, electronic load torque limitation, endless pivoting, hydraulic brace support, and remote control.

Hydraulic loading cranes HMF 6020-OK6

Technical specs - 6020-OK6 HMF

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Load Torque
517 kNm
machine length
2.5 m
machine width
1.46 m
machine height
2.425 m
max. standard boom
17 m
Carrying capacity
2.64 t
at max. reach
16.9 m
Load of additional Jib
0.4 t
Weight
6.225 t
Model series
RCS

More technical details, like: max. carrying capacity, at reach, max. hook height, required power are available in the full technical specs.

unmounted without accessories LMB = load torque limit Schwb.= pivot range

Special equipment

Hydr. brace support
Yes
Electronic load torque limitation
Yes
Endless pivoting
Yes
High seat
No
Remote control
Yes
Adjustable pivoting
Yes
Articulated boom overstraining
No

Download datasheets (PDF)
